18923 VHF/UHF LMR Harmonic Reject Filter
This filter prevents VHF & UHF land mobile radio transmitter harmonic emissions from interfering with wireless services operating between (698 – 2000) MHz. Features: Compa
Description
Details: This filter prevents VHF & UHF land mobile radio transmitter harmonic emissions from interfering with wireless services operating between (698 – 2000) MHz. Features: Compact Size for Easy Installation Applications: Prevent Interference to Collocated or Nearby Wireless Services (e.g. – 700 MHz Band, GSM 850, GSM 1900, etc.)
Product Specifications
| Passband | 150 – 465 MHz |
| Passband Loss | 1 dB Approx |
| Passband VSWR (Max) | 1.5:1 |
| Power Rating (CW) | 100 Watts Max |
| Rejection | 80 dB Min from 698 – 2000 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Dimensions | 89mm x 51mm x 38mm |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 5.1 × 8.9 × 3.8 cm |
| Brand | Microwave Filter Company |
| Filter Type | Harmonic Filter |
| Passband | 150 – 465 MHz |
| Passband Loss | 1 dB Approx |
| Passband VSWR (Max) | 1.5:1 |
| Power Rating (CW) | 100 Watts Max |
| Rejection | 80 dB Min from 698 – 2000 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Dimensions | 89mm x 51mm x 38mm |
