14442 PCS Receive Filter
Ideal for use in broadcast-dense locations, this bandpass filter provides superior isolation from virtually all undesired transmissions … from AM to WiMax!
Description
Details: Ideal for use in broadcast-dense locations, this bandpass filter provides superior isolation from virtually all undesired transmissions … from AM to WiMax!
Product Specifications
| Application | Receive |
| Passband Receive | 1850-1910 MHz |
| Passband Insertion Loss | 1.0 dB Max |
| Passband Return Loss | 18 dB Min |
| Rejection | 60 dB Min, 70 dB Min, 55 dB Min |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | Up to 90%, Non-Condensing |
| Impedance | 50 ohms |
| Connectors | N Female |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Brand | Microwave Filter Company |
| Filter Type | Receive Filter |
| Application | Receive |
| Passband Receive | 1850-1910 MHz |
| Passband Insertion Loss | 1.0 dB Max |
| Passband Return Loss | 18 dB Min |
| Rejection | 60 dB Min, 70 dB Min, 55 dB Min |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | Up to 90%, Non-Condensing |
| Impedance | 50 ohms |
| Connectors | N Female |
