RF-Design FlexLink S9E-1616-75F

The FlexLink S9E-1616 is a professional L-Band Switch Matrix coming in a compact 1RU/19″ rack-mount Chassis supporting L-Band and also Extended L-Band frequency range (850…2450MHz), useable for Ka-Band and HTS applications. The unit comes with a 16.16 I/O configuration. It features variable gain control, slope equalization, RF power monitoring, switchable LNB-supply, 10MHz external ref. signal input and 1:1 redundant dual power supply. The unit is available with 50Ohm or 75Ohm RF connectors. A LC-Display with keypads allows easy local configuration. Remote configuration can be done via its Ethernet-interface (http./WebGUI, SNMPv2c).

L-Band Switch Matrix 16:16, 75Ohm F(f), variable gain control,slope equalization, RF power monitoring, switchable LNBsupply, 10MHz external reference, LC-Display/keypads, Ethernet-Interface (WebGUI, SNMP), 1:1 redundant power
supply, 1RU/19″ rackmount HS-Code: 85176200.
Dimension Net: each,
Weight Net: 6,00Kg each,
Packing: 1,00 x Box,
Dimension: 55x50x13cm each,
Gross Weight: 7,00Kg each,
Total-Weight: 7Kg,
ECCN: EAR99
Remark: Please see datasheet for other RF impedance & connectors
