Description
Contact: Tel / WhatsApp: +86 18688706870 | Web: www.nosatr.com
The FlexLink-K4 is a professional, flexible and scalable L-Band Switch Matrix in 4RU/19″ rack mount design supporting Extended L-Band frequency range (850 – 2450MHz), useable for standard L-Band, KA-Band and HTS applications. It allows various switch/routing configurations from 4:4 to 32:32 (increments of 4) where one input can be switched/routed to one or all outputs (fan-out/distributive). The system comes in two versions, the K4-Eco and the K4-Plus both available with max. 32 inputs and 32 outputs. The K4-Eco system is a standard unity gain matrix while the K4-Plus comes with additional features such as variable gain-control, slope equalization, RF power monitoring and optionally with LNB-supply and 10MHz external reference signal port.
Features & Benefits
-
4RU/19″ rackmount design
-
Configurations 4:4 to 32:32
-
Extended L-Band (850 – 2450MHz)
-
10MHz reference signal port
-
Various input & output coax connectors (50 & 75OHm)
-
Variable gain control
-
Slope equalization
-
RF power monitoring
-
Switchable LNB-supply
-
Superior RF performance
-
Front-side LCD touchscreen
-
Remote configuration via WebGUI
-
and more …
The K4–Eco system is a standard unity gain matrix while the K4– Plus comes with additional features such as variable gain control,
slope equalization, RF power monitoring and optionally with switchable LNB–supply and 10MHz external reference signal port.
The FlexLink–K4 Matrix Systems are designed for todays and future signal management requirements e.g. in Satellite downlink
operations providing maximum flexibility as well as a space and cost efficient solutions. A front panel touchscreen allows easy local configuration. Remote configuration can be done via its Ethernet–Interface (WebGUI, SNMP).
