HS-PA Series Satellite Communication RF Power Amplifier Technical Datasheet

Document No.: HS-PA-2026-EN

Document Type: Satellite Communication / RF System Engineering Datasheet

Product Line: HS-PA Series 100W GaN Hybrid Power Amplifier

Frequency Coverage: 300 MHz – 6000 MHz (12 continuous sub-bands)

Typical Applications: VSAT Earth Station, Satellite Communication Terminal, Telemetry & Telecontrol Link, UAV Data Link, Electronic Warfare System, Laboratory RF Test

Product Overview

The HS-PA series is a high-efficiency GaN (Gallium Nitride) hybrid power amplifier family designed for satellite communication and broadband radio systems. The product lineup consists of 12 models, covering full frequency bands from UHF to C-Band (300 MHz to 6000 MHz), with each model supporting a continuous 500 MHz sub-band.

Engineered for harsh operating conditions of satellite-ground links, airborne and ship-borne RF frontends, the HS-PA series delivers stable performance, high integration and wide compatibility. It serves as a high-power signal amplification solution for professional satellite communication and RF testing scenarios.

Core Features	Engineering Advantages (Satellite System Perspective)
≥100 W Saturation Output Power (Psat)	Meets EIRP budget requirements for VSAT uplink channels, provides sufficient fade margin to ensure stable long-distance satellite-ground transmission.
50 dB Typical Gain, ≤3 dBm Drive Level	Directly driven by intermediate frequency upconverters or low-power modems, simplifying RF chain architecture and reducing system integration costs.
GaN Final Stage, PAE ≥30%	High power efficiency significantly reduces heat dissipation, ideal for space-constrained and power-limited portable, airborne and ship-borne platforms.
4-Way Protection Mechanism	Automatic shutdown triggered by over-temperature, over-voltage, over-current and VSWR mismatch, supporting 24/7 unattended operation.
Industrial Temperature Range: -20°C ~ +85°C	Fully adaptable to outdoor earth stations, vehicle-mounted SATCOM-on-the-move and UAV external cabin deployment.
Spurious Emission ≥65 dBc, 2Fo ≥-12 dBc	Complies with standard satellite communication emission masks, ensuring high spectral purity and no interference to adjacent satellite channels.
Plug-and-Play Tray Structure	Standard 7W2 power & control interface enables fast system integration, equipment replacement and convenient maintenance.

Key Performance Parameters

Parameter	Specification
Frequency Range	300 MHz – 6000 MHz (12 × 500 MHz continuous sub-bands)
Saturated Output Power (Psat)	≥ 100 W
Small Signal Gain (Typ.)	50 dB
In-band Gain Flatness	≤ 3 dB
Input Drive Level	≤ 3 dBm (Nominal)
Input VSWR	≤ 1.5
Spurious Suppression	≥ 65 dBc
Second Harmonic Suppression (2Fo)	≥ -12 dBc (Typ.)
Power Added Efficiency (PAE)	≥ 30%
Operating Current	≤ 12 A @ 28 V DC
Operating Temperature	-20°C ~ +85°C
Weight	≈ 1000 g

General Electrical Specifications

The following specifications apply to all 12 models of the HS-PA series, excluding frequency range and mechanical dimensions.

No.	Parameter	Specification
1	Operating Frequency	Model-dependent, full coverage 300 MHz – 6000 MHz
2	Input Power	≤ 3 dBm nominal drive
3	Saturated Output Power	≥ 100 W
4	Gain Flatness	≤ 3 dB
5	Typical Gain	50 dB
6	Protection Functions	Over-temperature, Over-voltage, Over-current, VSWR Mismatch Protection
7	Current & Efficiency	≤ 12 A, PAE ≥ 30%
8	Input VSWR	≤ 1.5
9	Spurious Suppression	≥ 65 dBc
10	Harmonic Suppression	≥ -12 dBc @ 2Fo (Typ.)
11	RF Input Connector	SMA-50K (Female)
12	RF Output Connector	N-50K (Female)
13	Power & Control Interface	7W2 Hybrid Connector, 28 V DC
14	PTT / Enable Control	5 V TTL, High Level Active
15	DC Supply Voltage	+28 V ~ +32 V DC
16	Dimension (Excl. Connector)	Low band(01–06): 180 × 90 × 25 mmHigh band(07–12): 200 × 120 × 25 mm
17	Operating Temperature	-20°C ~ +85°C
18	Cooling Requirement	External heat sink required during operation and testing
19	Weight	≈ 1000 g

Model Selection Table

Model	Frequency Range	Band Classification	Part Number
Model 01	300 – 800 MHz	UHF	HS-PA-0308
Model 02	800 – 1300 MHz	L-Band	HS-PA-0813
Model 03	1300 – 1800 MHz	L-Band	HS-PA-1318
Model 04	1800 – 2300 MHz	S-Band	HS-PA-1823
Model 05	2300 – 2800 MHz	S-Band / Wi-Fi	HS-PA-2328
Model 06	2800 – 3300 MHz	S/C-Band	HS-PA-2833
Model 07	3300 – 3800 MHz	C-Band	HS-PA-3338
Model 08	3800 – 4300 MHz	C-Band	HS-PA-3843
Model 09	4300 – 4800 MHz	C-Band	HS-PA-4348
Model 10	4800 – 5300 MHz	C-Band / 5 GHz
