CPI C240FA 2.4 Meter Motorized Flyaway Antenna

The CPI Satcom & Antenna Technologies Inc. (CPI SAT) lightweight 2.4 meter motorized flyaway antenna is designed for worldwide transmit and receive operation in C, X, Ku and Ka-Band. This flyaway antenna consists of a carbon fiber composite reflector, a cable-driven elevation-over-azimuth positioner and an aluminum /CFRP support structure. This results in a low-weight, motorized antenna with superior stiffness and high performance under wind loading conditions. The unique shape and the accurate reflectors surface provide exceptionally low sidelobe and cross-polarization performance meeting INTELSAT and EUTELSAT requirements. Repeatability is maintained with precision registration of the nine reflector segments and the feed support structure. The interchangeable feeds are palletized for quick, easy removal and replacement, allowing the end-user to effectively change frequency bands in the field within minutes. The complete antenna system, including a single feed and a motorized positioner is packaged in eight robust, portable cases.

Features

• Carbon fiber reflector: lightweight, precision surface and high stiffness
• Cable-driven positioner: composite/aluminum construction,
• Easy deployment: two-person assembly in less than 30 minutes, captive hardware and precision alignment. No tools required for assembly
• Auto-acquisition with DVB reference
• 100-240 VAC input
• High performance: Low sidelobes and high EIRP capability – FCC, ITU, DISA, ARSTRAT sidelobe compliant

Options

• Finishes

Standard ford polar white reflector / feed

Options: green feed std. 595 34094 or desert sand feed std. 595 33303

• Controller

Options acquisition DVB and/or beacon receiver

Spectrum analyzer display feature

• Integration

SSPB and/or LNB

Specify at time of order
