CPI 4.6 Meter Prime Focus Antenna

The CPI Antenna Technologies’ 4.6 meter antenna delivers exceptional performance for receive-only applications for C through Ku-band frequencies.

The antenna offers a prime focus reflector that incorporates precision-formed panels, contoured radials and hub assembly. The reflector is supported by a galvanized pedestal that provides the required stiffness for pointing and tracking accuracy. The pedestal is designed for full orbital arc coverage and can be readily adaptable to ground or rooftop installations. A low cost motorization and control system features is also available.

Features

• Bolt-together system
• 3.4 to 12.75 GHz operation
• Durable FRP reflector 1
• 25 mph (200km/h) wind survival
• Fully motorized

Options

• C, X, Ku, and C/Ku-band feed configurations
• C/Ku receive-only feed system
• Specialized feed systems (e.g., extended, multi-band)
• Improved feed cross-pol performance
• Fixed or motorizable pedestal
• Antenna control system with tracking
• Integrated LNA or LNB systems
• Load frame or non-penetrating mounts
• Packing for sea and air transport
• Turnkey installation and testing

Upgrades

• Extended azimuth travel
• Low operating temperatures
