CPI 4.0M LEO/MEO Gateway Terminals

CPI®’s new 4.0m gateway terminals are designed to establish robust connections with modern LEO and MEO satellite constellations.

These terminals feature premium materials such as carbon-fiber composites resulting in a stiff and efficient design and eliminating the need for radomes.

With an embedded controller and beacon receiver, coupled with integrated CPI RF electronics, these terminals are upgradable to accommodate any future networks.

The gateway terminals’ software-guided commissioning and calibration routine supports hassle-free set up and deployment. The design also eliminates the need for costly and time-consuming field alignment.

These gateways terminals perform exceptionally at Ka- and Q/V-band frequencies. The innovative positioner design features no zenith keyhole for uninterrupted overhead passes.

With one-day installation and operation-readiness, CPI’s gateway terminals are tailored to meet the high-volume demands of modern LEO and MEO satellite constellations.

Features:

• Designed for superior performance at Ka and Q/V-band
• Fully integrated with CPI RF electronics and upgradable to future networks
• Embedded controller and beacon receiver for robust acquisition and tracking of all orbits
• Engineered for easy installation and set up with minimal training
• State-of-the-art calibration and commissioning software
• Robust atmospheric tolerance of conditions encountered in coastal regions or heavily industrialized areas
• Controlled remotely by HTML5 Web GUI, SNMPv3 or standard CLI
• Compliant with FCC and CE regulations. Intelsat, FCC, ITU and Eutelsat sidelobe compliant
• Superior packaging to withstand shock and vibration conditions encountered during shipment

Options:

• Anti-ice and radome options available
• 2.4m gateway terminals also available
