19337 700 MHz Band Bandpass Filter
This filter isolates LTE 700 MHz downlink bands 12, 13, 17 and 29 from undesired operations above and below those bands.
Description
Details: This filter isolates LTE 700 MHz downlink bands 12, 13, 17 and 29 from undesired operations above and below those bands.
Product Specifications
| Passband(MHz) | 715 – 757 |
| Passband I/L | 1 dB Max |
| Passband R/L | 14 dB Min |
| Stopband(s) (MHz) | 685 & 778 |
| Stopband Attenuation | 55 dB Approx |
| Connectors | N-female |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 7.4 × 31.9 × 9 cm |
| Brand | Microwave Filter Company |
| Filter Type | Bandpass Filter |
| Passband(MHz) | 715 – 757 |
| Passband I/L | 1 dB Max |
| Passband R/L | 14 dB Min |
| Stopband(s) (MHz) | 685 & 778 |
| Stopband Attenuation | 55 dB Approx |
| Connectors | N-female |
