16695 PPDR (4.9 GHz) Full Band Filter
This filter achieves low loss within the 4.9 GHz band and provides superior isolation from virtually all other transmission sources above and below the band. Ideal for use in PPDR
Description
Details: This filter achieves low loss within the 4.9 GHz band and provides superior isolation from virtually all other transmission sources above and below the band. Ideal for use in PPDR (Public Protection and Disaster Relief) telecom applications such as Homeland Security and other Public Safety Services.
Product Specifications
| Application | Bandpass (4940-4990) MHz |
| Passband | 4940-4990 MHz |
| Passband Loss | 1 dB Max |
| Rejection | 10 dB Min @ 4890 MHz, 10 dB (Min) @ 5040 MHz |
| Power Rating | 50 Watts (CW) |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Dimensions | 2.3” x 2.3” x 1.1” |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 5.84 × 5.84 × 2.79 cm |
| Brand | Microwave Filter Company |
| Filter Type | Filter |
| Application | Bandpass (4940-4990) MHz |
| Passband | 4940-4990 MHz |
| Passband Loss | 1 dB Max |
| Rejection | 10 dB Min @ 4890 MHz, 10 dB (Min) @ 5040 MHz |
| Power Rating | 50 Watts (CW) |
| Impedance | 50 ohms |
| Connectors | N-Female |
| Dimensions | 2.3” x 2.3” x 1.1” |
