Work Microwave VHSBD Synthesized Block Downconverter

Description

WORK Microwave’s synthesized block converters are designed to optimize the performance and bandwidth of satellite communications links, enabling operators to cost-effectively deliver a superior signal quality. Ideal use cases include fixed satellite ground stations as well as in satellite newsgathering (SNG) vehicles, fly-aways, and other mobile or portable applications. The fifth-generation frequency converter series is built with the most advanced technologies available to ensure outstanding performance, high reliability and a longer lifetime.

5 th -generation enhancements

Reduced phase noise: Based on a powerful new synthesizer the frequency converters achieve a phase noise significantly beyond the recommended industry specification (Intelsat’s IESS-308/309).

Optional slope compensation up to +8 dB / GHz over L-band: With slope compensation users can effectively balance the losses and negative slope of augmented cable runs to ensure that all signals entering the RF processing chain are at similar levels across all frequencies.

Improved flexibility and usability: Through a new USB port, operators can now access the converter via the back panel to make copies of parameter settings, replicate selected configurations on another device or save configuration settings for future reference. In addition, a user-friendly, Web-based interface offers an intuitive user experience. When coupled with the enhanced USB port, the customizable GUI also simplifies the installation of firmware updates.

Higher reliability: An AC power consumption of 45 VA / 35 W maximizes the reliability and lifetime of the units.

High signal integrity

The very low phase noise of the oscillators guarantees an excellent signal quality. Low spurious emissions allow our customers to use the converters in the environments with demanding requirements, such as high power video uplinks. Sophisticated temperature compensation guarantees the stability over a wide temperature range.

Block converter with frequency synthesizer

In contrast to block converters with fixed or switchable LO these converters include a tunable LO with 100 Hz step size. The frequency bandwidth is selected to achieve low spurious emissions. These properties allow wideband frequency coverage with only one unit, where other concepts with fixed block converters require several different block converter modules.

Orders information

WORK Microwave offers three series of 19” rack satellite converters: Standard-, High- and Extra High Performance. The specifications are the same for all types except the operating temperature range. The High Performance type operates between -30 °C to 60 °C (-22 °F to 140 °F), the Extra High Performance type between -40 °C to 60 °C (-40 °F to 140 °F) and the Standard type between 0 °C to 50 °C (32 °F to 122 °F). Therefore if you only need units for inside use, the standard unit is perfectly suited for this application.
