KEY SPECIFICATIONS
| antenna aperture | 1.2m |
|---|---|
| antenna category | Flyaway |
| band | Ku-Band |
| number of onboard LOs | Single-Band |
| Product Revision | A |
ANTENNA SPECIFICATIONS
| antenna function | Transmit / Receive |
|---|---|
| antenna mount | Tri-pod Base Mount |
| antenna mount type | Elevation over Azimuth |
| antenna structure | Single Offset |
| azimuth angle | 360° (Continuous Fine Adjustment) |
| elevation angle | 0° to 90° (Continuous Fine Adjustment) |
| noise temperature@ 10.7 GHz receive 10-degree elevation unity | 68K |
| noise temperature@ 10.7 GHz receive 30-degree elevation unity | 53K |
RF SPECIFICATIONS
| Rx frequency | 10.7 – 12.75 GHz |
|---|---|
| RX interface | WR75 |
| Tx frequency | 13.75 – 14.5 GHz |
| TX interface | WR75 |
ENVIRONMENTAL SPECIFICATIONS
| temperature survival | -40°C to +140°C / -40°C to +60°C |
|---|---|
| windspeed operational | No Ballast/Anchors: 25 mph / 40 Kmh; with Ballast/Anchors: 45 mph / 72 kmh |
| windspeed survival | With Ballast/Anchors: 90 mph gusts / 145 Kmh Gusts |
PHYSICAL SPECIFICATIONS
| product height | 1200 mm |
|---|---|
| product length | 1200 mm |
| product width | 609.6 mm |
INFORMATION
| HS Code | 8529102120 |
|---|---|
| Country of Origin | Made in USA |
| Ex Works | Richmond, BC, Canada |
| ECCN Number | EAR99 |
| Warranty | 1 year |
| Dangerous Goods | – |
| Unit Package Dimensions | 863.6 x 1041.4 x 520.7 mm |
| Unit Package Weight | 78.5 kg |
| Total Aluminium Content | – |
| Aluminum Country of Smelt and Cast | – |
| Total Aluminium Value | – |
