RF-Design RLA270A 1:1 redundant professional L-Band line amplifier

The RLA270A is a 1:1 redundant professional L-Band line amplifier with variable gain, slope-equalization, 10MHz external reference and switchable LNB-supply housed in a 1RU/19″ chassis. This line amplifier is perfectly suited for RF distribution infrastructures in Teleports, Satellite Earth-Stations, as well as Broadcast- and Broadband facilities wherever accurate RF power, highest stability and availability is necessary. It is equipped with two high dynamic 1:1 redundant operating amplifier-modules each providing variable gain so to achieve best performance within the network. The unit features adjustable gain, slope equalization, RF power monitoring, 10MHz ref., LNB-supply 1:1 redundant power-supply. The RLA270A has a front-side LC-Display/keypads for local configuration while front-side status LED´s indicating amplifier and power-supply status. Remote configuration can be done via the Ethernet-Interface (WebGUI, SNMP).

1+1 redundant L-Band Amplifier, max. gain 27dB, 2 amplifier modules, 50Ohm SMA(f), RF power monit., slope equaliz.,
LNB-supply, 10MHz ext. reference, status LED´s, LCD/ keypads, Ethernet-Interf. (WebGUI, SNMP), 1:1 redundant
power supply. 1RU/19″ rackmount.
HS-Code: 85437030
Dimension Net: each,
Weight Net: 4Kg each,
Packing: 1,00 x Karton,
Dimension: 55x50x13cm each,
Gross Weight: 5Kg each,
Total-Weight: 5Kg,
ECCN: EAR99
Remark: Please see datasheet for other RF impedance &
connectors.
