KEY SPECIFICATIONS
| antenna category | Maritime |
|---|---|
| band | Ku-Band |
| of onboard los | Single-Band |
| Product Revision | A |
ANTENNA SPECIFICATIONS
| antenna aperture | 1.2 m |
|---|---|
| antenna type | Ring Focus |
| auto acquisition time | ≤ 3min |
| azimuth acceleration | 200°/s² |
| azimuth velocity | ≤ 60°/s |
| blockage recovery time | ≤ 5s (Blockage 20min) |
| cross polarization isolation | 35 dB |
| elevation acceleration | 200°/s² |
| elevation veolcity | ≤ 60°/s |
| motion range AZ | 360° continuous |
| motion range EL | -15° – 125° |
| motion range POL | ± 90° |
| polarization | Linear |
| polarization acceleration | ≤ 40°/s |
| polarization velocity | ≤ 40°/s |
| sidelobe | AZ: ≤ -14dB (first side lobe) |
RF SPECIFICATIONS
| port isolation Rx-Tx | 85 dB |
|---|---|
| port isolation Tx-Rx | 85 dB |
| power capacity | 100 W |
| Rx frequency | 10.70 – 11.70 GHz |
| rx gain | 41.5+20lg(f/11.2) dBi |
| Rx interface | N-50K |
| Rx VSWR | 1.5 |
| Tx frequency | 12.75 – 13.25 GHz |
| tx gain | 42.7+20lg(f/13.0) dBi |
| Tx interface | WR75 |
| Tx VSWR | 1.5 |
ELECTRICAL SPECIFICATIONS
| power consumption | ≤400W (excluding BUC) |
|---|---|
| power supply | 220 VAC, 50 Hz |
INTERFACE SPECIFICATIONS
| positioning mode | GPS+BD |
|---|
ENVIRONMENTAL SPECIFICATIONS
| humidity | 0 – 95% |
|---|---|
| IP rating | IP65 |
| temperature operational | -40°C to +55°C |
| windspeed operational | 21m/s |
| windspeed survival | 35m/s |
PHYSICAL SPECIFICATIONS
| color | White |
|---|---|
| default cable (included) | Communication cables, Power supply cables, RF cables, Electrical power cables |
| default cable length | 10m |
| product weight | ≤ 150 kg (excluding BUC, LNB, case, packaging and accessories etc) |
| RMS | ≤ 0.5 dB (R.M.S) |
INFORMATION
| HS Code | 8529109090 |
|---|---|
| Country of Origin | – |
| Ex Works | Hong Kong |
| ECCN Number | EAR99 |
| Warranty | 1 year |
| Dangerous Goods | – |
| Unit Package Dimensions | – |
| Unit Package Weight | – |
| Total Aluminium Content | – |
| Aluminum Country of Smelt and Cast | – |
| Total Aluminium Value | – |
