ETL Systems GNS-391-ODU Genus Outdoor Unit With Internal 10 MHz reference source
The Genus outdoor unit (ODU) has a modular design which can house any combination of compatible modules within the unit. Supplying operators with a flexible and scalable solution, that reduces spare parts and space requirements. The ODU chassis houses up to 19 RF modules including Amplifiers, BUC/LNB Power Supply’s, Frequency Converters, Matrices, RF over Fibre, Redundancy Switches and Test Loop Translators, which can be mixed. The Genus chassis provides a cost-efficient solution with field-replaceable components. The RF modules are field-serviceable and can be inserted whilst the shelf is in service, giving excellent levels of flexibility and resilience. With additional reliability from dual redundant hot-swap power supplies & field serviceable RF modules, CPU and optional user replaceable internal and external 10MHz reference source & HMI. Available with the additional option of air-conditioning units for higher operating temperature environments. (Model GNS-391-ODU-A) and with heating for lower temperature operation (Model GNS-391-ODU-H). The integrated 10MHz card has full control and monitoring via the parent chassis HMI or RJ45. The 10MHz reference source is switchable between this on-board ovenised 10MHz oscillator or the customer supplied external reference, connected to the EXT input connector.
Description
Description: The Genus outdoor unit (ODU) has a modular design which can house any combination of compatible modules within the unit. Supplying operators with a flexible and scalable solution, that reduces spare parts and space requirements. The ODU chassis houses up to 19 RF modules including Amplifiers, BUC/LNB Power Supply's, Frequency Converters, Matrices, RF over Fibre, Redundancy Switches and Test Loop Translators, which can be mixed. The Genus chassis provides a cost-efficient solution with field-replaceable components. The RF modules are field-serviceable and can be inserted whilst the shelf is in service, giving excellent levels of flexibility and resilience. With additional reliability from dual redundant hot-swap power supplies & field serviceable RF modules, CPU and optional user replaceable internal and external 10MHz reference source & HMI. Available with the additional option of air-conditioning units for higher operating temperature environments. (Model GNS-391-ODU-A) and with heating for lower temperature operation (Model GNS-391-ODU-H). The integrated 10MHz card has full control and monitoring via the parent chassis HMI or RJ45. The 10MHz reference source is switchable between this on-board ovenised 10MHz oscillator or the customer supplied external reference, connected to the EXT input connector.
Downloads:
Additional information
| Weight | 18 kg |
|---|---|
| Brand | ETL Systems |
| Weight (kg) | 18.00 |
