Actox ABD40NKX- 40W Ext. Ku-Band Block Up Converter, F-Type

ABD40NKX – 40W Ext. Ku-Band Block Up Converter

This unit features:

Output frequency 13.75-14.50 GHz

Double- L.O. (switchable 12.80 & 13.05 GHz)

Based on GaN technology which enables high effi ciency, low power consumption and high reliability

Incomparable low power consumption (227W max.)

Auto-ranging powering option 86 – 240 VAC

Digital temperature compensation

Field-exchangeable (F/N) IF connector

Amplifi er, L.O. and 10 MHz Reference Status LEDs

M&C – combined RS-232/485/Ethernet (HTTP and SNMP) and optional FSK

RoHS compliant

Model

RF Frequency

Dual local oscillator

IF Frequency

Output Power

Connector

ABD40NKX

13.75 to 14.50 GHz

13.05 GHz and 12.80 GHz

950 to 1,700 MHz

40W (+46 dBm min.)

F-type

Parameter

Value

Output interface

Waveguide, WR-75

Output power

+46 dBm minimum over temperature

Conversion gain

70 dB typ.

Required frequency

10 MHz (sine-wave)

External reference input power

-5 to +5 dBm @ input port

Phase noise

-55 dBc/Hz max. @ 10 Hz

-65 dBc/Hz max. @ 100 Hz

-75 dBc/Hz max. @ 1 KHz

-85 dBc/Hz max. @ 10 KHz

-95 dBc/Hz max. @ 100 KHz

-115 dBc/Hz max. @ 1 MHz

Input V.S.W.R.

1.5 : 1 max

Output V.S.W.R.

1.5 : 1 max

Power requirement

+80 ~ +240 VAC via MS Connector, 199 W max

Mute

Shut off the HPA in case of L.O. unlocked

Input interface

F-type

M&C

RS-232 and RS-485

FSK

Multiplexed on TX IFL, compatible with Comtech and Paradise

Power consumption

199 W max.

Operating temperature

-40 to +55 degrees C

Storage temperature

-55 to +85 degrees C

Size (mm)

195 (L) x 120 (W) x 99 (H)

Weight

2.95 kg max. (6.50 lbs max.)

Key Specifications

Output interface	Waveguide, WR-75
Output power	+46 dBm minimum over temperature
Conversion gain	70 dB typ.
Required frequency	10 MHz (sine-wave)
External reference input power	-5 to +5 dBm @ input port
Phase noise	-55 dBc/Hz max. @ 10 Hz -65 dBc/Hz max. @ 100 Hz -75 dBc/Hz max. @ 1 KHz -85 dBc/Hz max. @ 10 KHz -95 dBc/Hz max. @ 100 KHz -115 dBc/Hz max. @ 1 MHz
Input V.S.W.R.	1.5 : 1 max
Output V.S.W.R.	1.5 : 1 max
Power requirement	+80 ~ +240 VAC via MS Connector, 199 W max
Mute	Shut off the HPA in case of L.O. unlocked
Input interface	F-type
M&C	RS-232 and RS-485
FSK	Multiplexed on TX IFL, compatible with Comtech and Paradise
Power consumption	199 W max.
Operating temperature	-40 to +55 degrees C
Storage temperature	-55 to +85 degrees C
Size (mm)	195 (L) x 120 (W) x 99 (H)
Weight	2.95 kg max. (6.50 lbs max.)

Documents

• Datasheet / User Manual
