19384 ISM (900 MHz) Partial Band Bandpass Filter
This bandpass filter isolates a portion of the ISM (900 MHz) band from potential interference from out of band transmissions.
Description
Details: This bandpass filter isolates a portion of the ISM (900 MHz) band from potential interference from out of band transmissions.
Product Specifications
| Application | Bandpass |
| Passband | 917 – 927 MHz |
| Passband Loss | 2 dB Approx |
| VSWR (Max) | 1.5:1 |
| Rejection | 70 dB Min @ 907 MHz and 933 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 3.49 × 6.85 × 2.63 cm |
| Brand | Microwave Filter Company |
| Filter Type | Bandpass Filter |
| Application | Bandpass |
| Passband | 917 – 927 MHz |
| Passband Loss | 2 dB Approx |
| VSWR (Max) | 1.5:1 |
| Rejection | 70 dB Min @ 907 MHz and 933 MHz |
| Impedance | 50 ohms |
| Connectors | N-Female |
