19336 BRS-EBS (2.5 GHz) Band Bandpass Filter
This filter isolates the upper portion of the BRS-EBS band from potential interference from other operations above and below the band.
Description
Details: This filter isolates the upper portion of the BRS-EBS band from potential interference from other operations above and below the band.
Product Specifications
| Passband or Center Frequency (Fo) | 2620 – 2690 MHz |
| Insertion Loss | 1.0 dB Approx |
| VSWR | 1.5:1 Max |
| Rejection | 60 dB Approx @ 2570 MHz, 60 dB Approx @ 2740 MHz |
| Package – Size | 8.03” x 1.98” x 1.25” |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 5 × 20.4 × 3.2 cm |
| Brand | Microwave Filter Company |
| Filter Type | Bandpass Filter |
| Passband or Center Frequency (Fo) | 2620 – 2690 MHz |
| Insertion Loss | 1.0 dB Approx |
| VSWR | 1.5:1 Max |
| Rejection | 60 dB Approx @ 2570 MHz, 60 dB Approx @ 2740 MHz |
| Package - Size | 8.03” x 1.98” x 1.25” |
