19125 BRS-EBS (2.5 GHz) Band Bandpass Filter
This filter isolates the upper portion of the BRS-EBS band from potential interference from other operations above and below the band.
Description
Details: This filter isolates the upper portion of the BRS-EBS band from potential interference from other operations above and below the band.
Product Specifications
| Passband or Center Frequency (Fo) | 2624 – 2690 MHz |
| Insertion Loss | 1 dB Max |
| VSWR | 1.5:1 Max |
| Rejection | 20 dB Min @ 2568 MHz, 20 dB Min @ 2746 MHz |
| Package – Size | 3.03” x 0.73” x 1.90” |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 1.9 × 7.7 × 4.8 cm |
| Brand | Microwave Filter Company |
| Filter Type | Bandpass Filter |
| Passband or Center Frequency (Fo) | 2624 – 2690 MHz |
| Insertion Loss | 1 dB Max |
| VSWR | 1.5:1 Max |
| Rejection | 20 dB Min @ 2568 MHz, 20 dB Min @ 2746 MHz |
| Package - Size | 3.03” x 0.73” x 1.90” |
