18494 GSM 900 Partial Band Receive Filter
This filter isolates a portion of the GSM 900 receive band from a lower portion of the GSM 900 receive band and from a portion of the GSM 900 transmit band.
Description
Details: This filter isolates a portion of the GSM 900 receive band from a lower portion of the GSM 900 receive band and from a portion of the GSM 900 transmit band.
Product Specifications
| Receive Band | 900-915 MHz |
| Passband Insertion Loss | 2.0 dB Max |
| Rejection | 60 dB Min from 870-885 MHz, 70 dB Min from 935-960 MHz |
| Connectors | N Female |
| Impedance | 50 ohms |
| Passband VSWR | 1.35:1 |
Datasheet: Download PDF
Additional information
| Weight | 1 kg |
|---|---|
| Brand | Microwave Filter Company |
| Filter Type | Receive Filter |
| Receive Band | 900-915 MHz |
| Passband Insertion Loss | 2.0 dB Max |
| Rejection | 60 dB Min from 870-885 MHz, 70 dB Min from 935-960 MHz |
| Connectors | N Female |
| Impedance | 50 ohms |
| Passband VSWR | 1.35:1 |
