Work Microwave A-Series AX-61 Satellite Modem
The AX-61 Satellite Modem is a modem for bidirectional streaming over DVB links, operating through ASI interfaces. It is suitable to fit into transport stream b…
Description
The AX-61 Satellite Modem is a modem for bidirectional streaming over DVB links, operating through ASI interfaces. It is suitable to fit into transport stream based communication systems with external generation and decoding of the streams. A wide range of license-based extensions equally allows internal data processing for network operation, space communications, and others.
Key Features:
- DVB-S2X – ETSI EN 302 307-2
- DVB-S2 – ETSI EN 302 307-1
- DVB-S2X modulations: QPSK to 256APSK normal, short, linear
- DVB-S2 modulations: QPSK to 32APSK; normal, short
- Symbol rates from 100 ksps to 75 Msps
- Data rate up to 360 Mbit/s integrated
- Roll-Off: 35%, 25%, 20%, 15%, 10%, 5%
- Exceptionally clean signal output and internal processing
- Predistortion for automatic group delay and nonlinearity compensation
- Operates as layer 3 bridge or layer 3 router including traffic shaping / QoS functionality
- ACM controller open to various ACM systems GSE and MPE encapsulation integrated
- Customizable processing infrastructure for easy integration into large communication systems
- Flexible software architecture for easy extension and future virtualization of functionality
- 3 years warranty
Contact Us:
Tel / WhatsApp: +86 18688706870
Website: www.nosatr.com
Images have been processed with a clean white background and watermark for www.nosatr.com.
Additional information
| Brand | Work Microwave |
|---|---|
| Product Family | Modem |
