WAYFARER 0.6m X-Band Auto Flyaway Antenna – Feed Forward
¥49,500.00
acquisition and tracking: Automatic
Description
Specifications
KEY SPECIFICATIONS
| acquisition and tracking | Automatic |
|---|---|
| antenna aperture | 0.6m |
| antenna category | Flyaway |
| band | X-Band |
| number of onboard LOs | Single-Band |
| Product Revision | A |
ANTENNA SPECIFICATIONS
| antenna type | Feed Forward |
|---|---|
| axis ratio | ≤ 1.5dB |
| azimuth angle | ± 180° |
| elevation angle | 10° – 90° |
| polarization | Circular |
| sidelobe | First sidelobe ≤ -14 dB |
RF SPECIFICATIONS
| port isolation Rx-Tx | 85 dB |
|---|---|
| port isolation Tx-Rx | 85 dB |
| power capacity | 100 W |
| Rx frequency | 7.25 – 7.75 GHz |
| rx gain | ≥ 30.44dBi+20lg(f/7.25GHz)dBi |
| Rx interface | WR112 |
| Rx VSWR | ≤ 1.5：1 |
| Tx frequency | 7.90 – 8.40 GHz |
| tx gain | ≥ 31.7dBi+20lg(f/7.9GHz)dBi |
| Tx interface | WR112 |
| Tx VSWR | ≤ 1.5：1 |
INTERFACE SPECIFICATIONS
| positioning mode | Beacon/DVB carrier |
|---|
ENVIRONMENTAL SPECIFICATIONS
| humidity | 95% (20℃) |
|---|---|
| IP rating | IP 65 |
| temperature operational | -35°C to +60°C |
| temperature storage | -50 °C to +70°C |
| windspeed operational | ≤ 11m/s |
| windspeed survival | ≤ 18m/s |
PHYSICAL SPECIFICATIONS
| color | White |
|---|---|
| default cable (included) | Power Supply and RF cable |
| default cable length | 10m |
| product weight | ≤ 18 kg (excluding BUC, LNB, packaging and accessories) |
| RMS | 0.3dB |
INFORMATION
| HS Code | 8517710000 |
|---|---|
| Country of Origin | Made in China |
| Ex Works | Hong Kong |
| ECCN Number | EAR99 |
| Warranty | 1 year |
| Dangerous Goods | – |
| Unit Package Dimensions | – |
| Unit Package Weight | – |
| Total Aluminium Content | 0 kg |
| Aluminum Country of Smelt and Cast | – |
| Total Aluminium Value | $ 0 |
