Ultra-High-Density Video Encod 4K 8K HEVC/H.265UHD4K超高清编码器

Description

Ultra-High-Density Video Encoding Platform​
​Future-Ready Infrastructure for Next-Gen Broadcast & Streaming​

---

​Overview​

This ​6-Module High-Integration Digital Frontend Platform​ redefines versatility in broadcast and streaming workflows. Designed for scalability and cost efficiency, it combines ​4x3G-SDI (4K H.265) Ultra HD encoders, ​HD-SDI encoders, ​digital/analog audio encoders, and ​analog video encoders​ into a single chassis. Each module is hot-swappable and independently configurable, making it ideal for DVB-T/T2, ATSC, IPTV, OTT, and satellite systems.

---

​Core Advantages​

✅ ​Modular Flexibility: Mix-and-match 6 customizable modules (SDI, audio, video) to match your workflow.
✅ ​Dual Power Redundancy: Built-in dual power supplies for uninterrupted 24/7 operation.
✅ ​Smart Output Options:

• ​2x ASI Outputs​ (BNC, 75Ω)
• ​1G/10G Adaptive IP Output​ (100/1000Base-T)
• Supports multicast, unicast, and cross-network segment configurations.
  ✅ ​Web-Based Control: Intuitive HTML5 interface with LCD panel for remote/local management.

---

​HEVC/4K Encoder Module​

​Input:

• ​4x3G-SDI BNC​ (75Ω), supporting 4K60/50/30 (3840x2160p) and downscaling.

​Encoding Power:

• ​Codecs: H.265 (HEVC)/H.264 (AVC)/MPEG-2.
• ​Resolutions: 2160p, 1080p/i, 720p, 576p/i, 480i.
• ​Bitrate & Quality: 2–80 Mbps CBR/VBR, 10-bit color depth, HDR10/HLG support.
• ​Audio: 4 stereo pairs (MPEG-1 Layer II, AAC, Linear PCM).

​Output:

• ​ASI: 2x BNC (≤200 Mb/s).
• ​IP: 1GigE port with adaptive bitrate streaming (RTMP, HLS, MPEG-TS).
• ​Latency: Ultra-Low Latency Mode (80ms in low-latency profile).

---

​Technical Specs​

---

​Design & Application​

🌟 ​Broadcast-Grade Reliability: ASI/IP hybrid outputs for seamless integration with CATV, satellite, and IPTV headends.
🌟 ​Cost-Efficient Scalability: Deploy 1 module for basic HD needs or max out 6 modules for 4K UHD workflows.
🌟 ​Global Compatibility: Supports DVB, ATSC, and ISDB standards; HDR10/HLG for cutting-edge displays.

---

​Why Choose This Platform?​​

• ​Future-Proof: Ready for 8K upgrades and AV1 codec transitions.
• ​Unified Workflow: Replace multiple single-function encoders with a single, scalable solution.
• ​Proactive Management: Real-time monitoring, SNMP alerts, and remote firmware updates.
