S band LNA

S band LNA

¥3,800.00

Compare
Category:

Description

Product Overview

Products manufactured by Shenzhen Huashi Digital Technology Co., Ltd. cover P, L, S, C, X, Ku, Ka, Q and V frequency bands as well as ultra-wideband applications, with customized extended frequency reception available. The products support 1:1 or 1:2 redundant backup for enhanced reliability. They are widely deployed in satellite communication, remote sensing detection, navigation and positioning, electromagnetic compatibility (EMC), aerospace TT&C, radio & television broadcasting, emergency support, low-altitude economy and many other fields, suitable for fixed earth stations, mobile stations and various other application scenarios.

Technical Features

  • Extremely low noise temperature
  • Customizable extended frequencies with multiple operating bandwidth options
  • Low power consumption and high cost performance
  • Easy installation and convenient maintenance
  • Domestic and self-controllable components

Optional Functions

  • 1:1 or 1:2 redundant backup function
  • Out-of-band rejection function
  • Overload protection and limiting protection functions
  • Optional interface types, power supply voltages and power supply modes
  • LNA fault alarm and power supply unit

S

Model Number Operating Frequency Gain Noise Temperature Out-of-Band Rejection Output P1dB Input VSWR Output VSWR Input Interface Output Interface Power Interface Power Supply Voltage
GH-LSC50DGD 2.2～2.7GHz ≥50dB 50K / ≥+10dBm 1.30 1.30 N-50K N-50K SMA-50K +12～+18VDC
GH-LSB50DHD 1.5～2.2GHz ≥40dB 50K / ≥+10dBm 1.5 1.5 N-50J N-50K 航插 +12～+18VDC
GH-LSA50DGD 2.2～2.3GHz ≥50dB 50K / ≥+10dBm 1.5 1.5 N-50K N-50K SMA-50K +12～+18VDC
GH-LSB75DGD 1.5～2.7GHz ≥50dB 75K / ≥+10dBm 2.0 1.5 N-50J N-50K SMA-50K +12～+18VDC
GH-LSF55DGD 2.0～3.2GHz ≥40dB 55K / ≥+10dBm 1.5 1.5 N-50K N-50K SMA-50K +12～+18VDC
GH-LSA45DHD-F0 2.2～2.3GHz ≥50dB 45K ≥35dBc@2000～2120MHz ≥+10dBm 1.25 1.3 N-50K N-50K 航插 +12～+18VDC
GH-LSC110AHD-F 2.48～2.54GHz ≥50dB 110K ≥35dB@2.66GHz ≥40dB@2.7GHz ≥40dB@2.0GHz ≥60dB@1.8GHz ≥+10dBm 1.3 1.35 BJ26 N-50K 航插 +22～+28VDC
GH-LSC100DGD 2.2～2.7GHz ≥50dB 150K ≥50dB@0.9～1.9GHz ≥+5dBm 1.3 1.3 N-50J N-50K SMA-50K +12～+18VDC
GH-LSC70DGD-F0 2.1～2.6GHz 60±3dB 70K ≥30dBc@800～2170MHz @2240～2485MHz @2555～3000MHz ≥+10dBm 1.5 1.3 N-50K N-50K SMA-50K +12～+18VDC
GH-LSA50DHD-F0 2.2～2.3GHz 50±1dB 50K ≥30dBc@2000～2120MHz ≥+10dBm 1.35 1.35 N-50K N-50K 航插 +12～+18VDC
