Description
RevGo designs and manufactures satellite earth station RF from low to high power. RevGo was founded in 2002 with its headquarters in the Washington DC corridor. RevGo’s broad VSAT product line is produced to stringent quality standards using an ISO9001:2015 quality system:
- Block upconverter (BUC)
- Low noise block (LNB)
- Transceiver (Tx/Rx/OMT/filters)
- C-, Ku-, DBS-, Ka-bands
- 2 to 300W output power
Product Features
- Five software selectable sub-bands in 27.5-30 GHz frequency range
- Power consumption 40W BUC 80W BUC 350W (@46dBm) 450 W (@49 dBm) 225W (@43dBm) 300 W (@47 dBm)
- Compact and light weight 12 lbs / 5.8 kg
- Both products can use “same” antenna system and mounts
- Dual-fans independently removable without causing service interruption
- Low phase noise (exceeds IESS308/309)
- Optimal flatness
- Rugged design for extreme environments (-40 to +60oC)
- M&C with real-time clock, event log, web interface, Open-BMIP (BMIP calibration table is an option)
