Norsat 9000HBN 9000HBN Single-Band Ka-Band PLL LNB – DEMO
¥563.00
KEY SPECIFICATIONS Band Ka-Band Input Frequency Band 1 19.20 – 20.20 GHz LO Frequency 1 18.25 GHz LO Type PLL Noise Figure Max 1.4 dB Noise Figure Typ 1.5 dB Number Of Onboard Los Single-Band Output Frequency Band 1 950 – 1950 MHz RF SPECIF
Description
| KEY SPECIFICATIONS | |
| Band | Ka-Band |
| Input Frequency Band 1 | 19.20 – 20.20 GHz |
| LO Frequency 1 | 18.25 GHz |
| LO Type | PLL |
| Noise Figure Max | 1.4 dB |
| Noise Figure Typ | 1.5 dB |
| Number Of Onboard Los | Single-Band |
| Output Frequency Band 1 | 950 – 1950 MHz |
| RF SPECIFICATIONS | |
| Conversion Gain Max | 65 dB |
| Conversion Gain Min | 55 dB |
| Conversion Gain Typ | 60 dB |
| Gain Flatness (Over Full Band) | 5 dB p-p |
| ELECTRICAL SPECIFICATIONS | |
| Current Consumption | 300 mA |
| Power Requirements | +15 to +24V DC |
| INTERFACE SPECIFICATIONS | |
| IF Connector | N-Connector |
| RF Input Connector | WR-42 waveguide grooved |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -40 to +60°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 45 mm |
| Product Length | 122 mm |
| Product Weight | 0.35 kg |
| Product Width | 60 mm |
| ADDITIONAL INFORMATION | |
| ECCN Number | EAR99 |
| Unit Package Dimensions | 122 x 60 x 45 mm |
| Unit Package Weight | 0.3 kg |
| Warranty | 1 years |
Additional information
| Band | Ka-Band |
|---|---|
| Input Frequency Band 1 | 19.20 – 20.20 GHz |
| LO Frequency 1 | 18.25 GHz |
| LO Type | PLL |
| Noise Figure Max | 1.4 dB |
| Noise Figure Typ | 1.5 dB |
| Number Of Onboard Los | Single-Band |
| Output Frequency Band 1 | 950 – 1950 MHz |
| Conversion Gain Max | 65 dB |
| Conversion Gain Min | 55 dB |
| Conversion Gain Typ | 60 dB |
| Gain Flatness (Over Full Band) | 5 dB p-p |
| Current Consumption | 300 mA |
| Power Requirements | +15 to +24V DC |
| IF Connector | N-Connector |
| RF Input Connector | WR-42 waveguide grooved |
| Temperature Operational | -40 to +60°C |
| Product Height | 45 mm |
| Product Length | 122 mm |
| Product Weight | 0.35 kg |
| Product Width | 60 mm |
| ECCN Number | EAR99 |
| Unit Package Dimensions | 122 x 60 x 45 mm |
| Unit Package Weight | 0.3 kg |
| Warranty | 1 years |
