Norsat 7100HPAF Ka-Band LNB
Original price was: ¥18,000.00.¥5,980.00Current price is: ¥5,980.00.
Norsat 7100HPAF is a Ka-Band LNB for satellite downlink reception. Input 17.20-18.20 / 18.00-19.00 / 18.70-19.70 / 19.40-20.40 / 20.30-21.30 GHz, noise 1.3 dB typ / 1.5 dB max, L-band output 950-1950 MHz via F-75 / N-50 (WR-42 input) connector.
Description
| Model | 7100HPAF |
|---|---|
| Series / Family | 7000 Series |
| Band | Ka-Band |
| Input Frequency | 17.20-18.20 / 18.00-19.00 / 18.70-19.70 / 19.40-20.40 / 20.30-21.30 GHz |
| Noise Figure / Temp. | 1.3 dB typ / 1.5 dB max |
| LO Frequency (GHz) | 16.25 / 17.05 / 17.75 / 18.45 |
| Stability | ±10 / ±25 / ±50 kHz |
| Reference / Lock | PLL (Internal Ref) |
| Output Frequency (L-band) | 950-1950 MHz |
| Connector | F-75 / N-50 (WR-42 input) |
| Source | Web (Official/Distributor) |
