Description
Specifications
KEY SPECIFICATIONS
| antenna category | Maritime |
|---|---|
| band | Ka-Band |
| of onboard los | Single-Band |
| Product Revision | A |
ANTENNA SPECIFICATIONS
| antenna aperture | 0.6m |
|---|---|
| antenna type | Ring Focus |
| auto acquisition time | ≤120s |
| azimuth acceleration | 200°/s² |
| azimuth velocity | 100°/s |
| blockage recovery time | Blockage time＜60s, Recovery time＜3s; 15min ≥ blockage time ≥ 60s, Recovery time＜10s |
| elevation acceleration | 200°/s² |
| elevation veolcity | 100°/s |
| motion range AZ | 690° |
| motion range EL | -10° – +115° |
| motion range POL | roll: -20° to +20° |
| polarization | Circular |
| polarization acceleration | roll: 200°/s² |
| polarization velocity | roll: 100°/s |
| sidelobe | First sidelobe ≤ -14 dB |
RF SPECIFICATIONS
| Rx frequency | 19.70 – 20.20 GHz |
|---|---|
| rx gain | 40.1dBi@19.95 GHz |
| Tx frequency | 29.50 – 30.00 GHz |
| tx gain | 44.0dBi@29.75 GHz |
ELECTRICAL SPECIFICATIONS
| power supply | 110 – 220V AC, typical power consumption 150W (excluding BUC) |
|---|
ENVIRONMENTAL SPECIFICATIONS
| humidity | 0 – 95% |
|---|---|
| temperature operational | -25°C to +65°C |
| temperature storage | -40°C to +85°C |
PHYSICAL SPECIFICATIONS
| color | White |
|---|---|
| default cable (included) | Communication cables, Power supply cables, RF cables, Electrical power cables |
| default cable length | 10m |
| product weight | 42 kg (excluding BUC) |
| RMS | ≤ 0.5 dB (R.M.S) |
INFORMATION
| HS Code | 8529109090 |
|---|---|
| Country of Origin | – |
| Ex Works | Hong Kong |
| ECCN Number | EAR99 |
| Warranty | 1 year |
| Dangerous Goods | – |
| Unit Package Dimensions | – |
| Unit Package Weight | – |
| Total Aluminium Content | – |
| Aluminum Country of Smelt and Cast | – |
| Total Aluminium Value | – |
