LNB Ku Band SIMULTANEOUS Lo 10GHz 11.3GHz

Description

LNB Ku Band SIMULTANEOUS BANDS EXT REF 9375HICN-2

TYPICAL SPECIFICATIONS

Noise figure LO stability	0.7 dB phase locked to external reference	Spurious -band Out-band	-60dBm max @room temp -55dBm max @over temp -40dBm max
Phase noise	-70dBc/Hz @ 1KHz -80dBc/ Hz @ 10 KHz	LO leakage (Input)	-50dBm max
Phase noise	-90dBc/ Hz @ 100KHz	Image rejection	40dBc min
Input VSWR	2.2 : 1	DC voltage / current	+13 to +20 V / 450mA
Output VSWR	2.0 : 1	Input waveguide	WR-75
Conversion gain	68dB typ.60dB min	Output connector	N-female/SMA/F
Gain flatness	±2 .5dB max/ ±0.75dB[Max.]@36MHz	Dimension	95.2 (L) x 51(W) x 41 .0(H) mm
Output P1dB	+5dBm min	Weight	485g
External reference	10 MHz, -5 to +5 dBm	Operating temperature	-40 to +70 °C
RF input level	-30dBm max	Waterproof Rating	IP67

* DC and 10MHz external reference need to be supplied to both IF output ports.

FREQUENCY BANDS AVAILABLE
