Jupiter Microwave JMC1200N Flexible Non Twistable Waveguide (WR28 to WR137)

Description

Details Jupiter Microwave MC1200T Flexible and Twistable Waveguide (WR28 to WR137) Flexible and Twistable Waveguide Flexible and twistable rectangular waveguides are used in a wide variety of satcom, VSAT and telecom applications that carry high frequency radio (microwave communications) signals. Flexible waveguides are manufactured from helically wound silver plated copper alloy strip material which allows the waveguides to twist and bend in the E and H planes simultaneously. The flexible waveguide core is protected from the environment by a molded neoprene rubber jacket providing durability and full axis of motion over the operating temperature range of –20 to +100 degrees Celsius. Waveguide Flanges Brass and aluminum waveguide flanges are manufactured in-house and maintained in inventory reducing product lead time so we can respond quickly to market demands. Both North American (EIA) and European (IEC) standard waveguide flanges are available in corrosion protected base metal or plated finishes. Accessories Hardware, fixing and clamping kit accessories are available for use with our flexible waveguide products. Electrical Specifications Waveguide Size Frequency Insertion Loss (Max) VSWR (Max) Power Rating (Watts) IEC R EIA WR Operating (GHz) dB/ft. (m) < 36 in. (1 m) 70 137 5.85-8.20 0.06 (0.20) 1.07 84 112 7.05-10.00 0.07 (0.23) 1.09 100 90 8.20-12.40 0.09 (0.30) 1.09 120 75 10.00-15.00 0.13 (0.43) 1.10 140 62 12.40-18.00 0.16 (0.52) 1.12 220 42 18.00-26.50 0.38 (1.25) 1.20 260 34 22.00-33.00 0.46 (1.50) 1.22 320 28 26.50-40.00 0.61 (2.00) 1.32 Mechanical Specifications Waveguide Size Bending Radius Rating Minimum for JMC1200T or JMC1200N Twisting Rating Maximum for JMC1200T Length Tolerance Internal Pressure Rating Maximum IEC R EIA WR E-Plane Static (In. mm) H-Plane Static (In. mm) E-Plane Repeated (In. mm) 70 137 4.0 (102) 8.0 (203) 16 (406) 84 112 3.0 (76) 6.0 (152) 12 (305) 100 90 2.5 (64) 5.0 (127) 10 (254) 120 75 2.1 (54) 4.3 (108) 8.5 (216) 140 62 1.8 (46) 3.6 (92) 7.0 (178) 220 42 1.2 (30) 2.3 (60) 4.7 (120) 260 34 1.0 (24) 1.9 (48) 3.8 (96) 320 28 0.8 (20) 1.6 (40) 3.2 (80)
