| Parameter |
Specification |
| |
Frequency range |
3.4 – 4.2 |
| |
Noise temperature |
30‘K max. |
| |
Conversion gain at -40 to +60℃ |
55 dB typ. (50dB min, 60dB max.). |
| |
Gain flatness |
4 dBp-p max. |
| |
Gain flatness at -40 to +60℃ |
4 dBp-p max. |
| |
Gain ripple at per 36MHz, -30 to +60℃ |
1 dBp-p max. |
| |
Output P1dB |
+5 dBm min. |
| |
Input VSWR |
2.2: 1 max |
| |
Output VSWR |
2.2: 1 max |
| |
Input waveguide flange |
WR-229 |
| |
Output connector |
N, SMA-type female (option) |
| |
Power connector |
MS3112E10-6P (option) |
| |
Power supply |
+12 to +24V DC |
| |
Required current |
250 mA max |
| |
Operating temperature |
-40 to +60℃ |
| |
Waterproof |
IP 67 |
| |
Dimension (exclude connector) |
98.8 x 70.0 x 164.5 mm |
| |
Weight |
630 g |
| |
|
|
