0.5-3GHz 100W Power Amplifier

Description

500‑3000MHz 100W Power Amplifier

100-1000MHz Power Amplifier Electrical Specifications

No.	Performance Item	Technical Parameters
1	Operating Frequency (MHz)	100 ~ 1000
2	Gain (dB)	≥55
3	CW Output Power (dBm)	50±1
4	Input Signal Power (dBm)	+5
5	Operating Current (A)	≤10
6	Input VSWR	≤1.5
7	RF Input Connector	SMA-F
8	RF Output Connector	N-F
9	Power Supply Interface	28V DC
10	PA Enable Voltage (V)	+28
11	Dimensions (Excluding Connectors) (mm)	165 × 115 × 24
12	Operating Temperature (℃)	-25 ~ +75
