Description

Model型号 Input Frequency (GHz) Noise Figure (dB) LO Stability LO Type Output Frequency (MHz) RF Output Connector
1008DXN-1 10.7 – 11.7 0.8 Locked Ext.Ref. External 950 – 1950 N-50 Ohm
1008DXF-2 10.95 – 11.7 0.8 Locked Ext.Ref. External 950 – 1700 F-75 Ohm
1008DXF-1 10.7 – 11.7 0.8 Locked Ext.Ref. External 950 – 1950 F-75 Ohm
1008DXN-2 10.95 – 11.7 0.8 Locked Ext.Ref. External 950 – 1700 N-50 Ohm
1208DHF-2 10.95 – 11.7 0.8 +/- 25 kHz PLL 950 – 1700 F-75 Ohm
1208DHF-1 10.7 – 11.7 0.8 +/- 25 kHz PLL 950 – 1950 F-75 Ohm
1108DHN-2 10.95 – 11.7 0.8 +/- 10 kHz PLL 950 – 1700 N-50 Ohm
1208DHN-1 10.7 – 11.7 0.8 +/- 25 kHz PLL 950 – 1950 N-50 Ohm
1108DHN-1 10.7 – 11.7 0.8 +/- 10 kHz PLL 950 – 1950 N-50 Ohm
1108DHF-1 10.7 – 11.7 0.8 +/- 10 kHz PLL 950 – 1950 F-75 Ohm
1108DHF-2 10.95 – 11.7 0.8 +/- 10 kHz PLL 950 – 1700 F-75 Ohm
1208DHN-2 10.95 – 11.7 0.8 +/- 25 kHz PLL 950 – 1700 N-50 Ohm
1007XHAF 11.70 – 12.20 0.7 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1008XHCF 10.95 – 11.70 0.8 Locked Ext.Ref. External 950 – 1700 F-75 Ohm
1007XHAN 11.70 – 12.20 0.7 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1008XHBN 12.25 – 12.75 0.8 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1007XHCF 10.95 – 11.70 0.7 Locked Ext.Ref. External 950 – 1700 F-75 Ohm
1008XHAN 11.70 – 12.20 0.8 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1009XHAN 11.70 – 12.20 0.9 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1007XHBF 12.25 – 12.75 0.7 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1008XHBF 12.25 – 12.75 0.8 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1009XHAF 11.70 – 12.20 0.9 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1008XF-2 11.70 – 12.75 0.8 Locked Ext.Ref. External 950 – 2000 F-75 Ohm
1008XG-2 12.20 – 12.70 0.8 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1008XHCN 10.95 – 11.70 0.8 Locked Ext.Ref. External 950 – 1700 N-50 Ohm
1009XHBN 12.25 – 12.75 0.9 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1008XEF 10.95 – 12.75 0.8 Locked Ext.Ref. External 950 – 2750 F-75 Ohm
1009XHBF 12.25 – 12.75 0.9 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1009XHCF 10.95 – 11.70 0.9 Locked Ext.Ref. External 950 – 1700 F-75 Ohm
1008XDN-2 10.70 – 11.80 0.8 Locked Ext.Ref. External 950 – 2050 N-50 Ohm
1008XHAF 11.70 – 12.20 0.8 Locked Ext.Ref. External 950 – 1450 F-75 Ohm
1007XHCN 10.95 – 11.70 0.7 Locked Ext.Ref. External 950 – 1700 N-50 Ohm
1007XHBN 12.25 – 12.75 0.7 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1008XD-2 10.70 – 11.80 0.8 Locked Ext.Ref. External 950 – 2050 F-75 Ohm
1008XFN-2 11.70 – 12.75 0.8 Locked Ext.Ref. External 950 – 2000 N-50 Ohm
1008XEN 10.95 – 12.75 0.8 Locked Ext.Ref. External 950 – 2750 N-50 Ohm
1008XGN-2 12.20 – 12.70 0.8 Locked Ext.Ref. External 950 – 1450 N-50 Ohm
1009XHCN 10.95 – 11.70 0.9 Locked Ext.Ref. External 950 – 1700 N-50 Ohm
1107HCF 10.95 – 11.70 0.7 +/- 10 kHz PLL 950 – 1700 F-75 Ohm
1108HBF 12.25 – 12.75 0.8 +/- 10 kHz PLL 950 – 1450 F-75 Ohm
1209HCF 10.95 – 11.70 0.9 +/- 25 kHz PLL 950 – 1700 F-75 Ohm
HS1029CF 10.95 – 11.70 0.9 +/- 2 kHz PLL 950 – 1700 F-75 Ohm
HS1037AF 11.70 – 12.20 0.7 +/- 3 kHz PLL 950 – 1450 F-75 Ohm
HS1038BF 12.25 – 12.75 0.8 +/- 3 kHz PLL 950 – 1450 F-75 Ohm
HS1038CF 10.95 – 11.70 0.8 +/- 3 kHz PLL 950 – 1700 F-75 Ohm
HS1048BF 12.25 – 12.75 0.8 +/- 4 kHz PLL 950 – 1450 F-75 Ohm
HS1057BF 12.25 – 12.75 0.7 +/- 5 kHz PLL 950 – 1450 F-75 Ohm
HS1057AF 11.70 – 12.20 0.7 +/- 5 kHz PLL 950 – 1450 F-75 Ohm
HS1057CF 10.95 – 11.70 0.7 +/- 5 kHz PLL 950 – 1700 F-75 Ohm
HS1059CF 10.95 – 11.70 0.9 +/- 5 kHz PLL 950 – 1700 F-75 Ohm
HS1027CN 10.95 – 11.70 0.7 +/- 2 kHz PLL 950 – 1700 N-50 Ohm
HS1039AN 11.70 – 12.20 0.9 +/- 3 kHz PLL 950 – 1450 N-50 Ohm
HS1049CN 10.95 – 11.70 0.9 +/- 4 kHz PLL 950 – 1700 N-50 Ohm
HS1059AN 11.70 – 12.20 0.9 +/- 5 kHz PLL 950 – 1450 N-50 Ohm
1108HAN 11.70 – 12.20 0.8 +/- 10 kHz PLL 950 – 1450 N-50 Ohm
1207HBN 12.25 – 12.75 0.7 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
1207HCN 10.95 – 11.70 0.7 +/- 25 kHz PLL 950 – 1700 N-50 Ohm
1207HAN 11.70 – 12.20 0.7 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
1209HBN 12.25 – 12.75 0.9 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
15008LBN 12.25 – 12.75 0.8 +/- 50 kHz PLL 950 – 1450 N-50 Ohm
15009LAN 11.70 – 12.20 0.9 +/- 50 kHz PLL 950 – 1450 N-50 Ohm
15009LB 12.25 – 12.75 0.9 +/- 50 kHz PLL 950 – 1450 F-75 Ohm
15009LA 11.70 – 12.20 0.9 +/- 50 kHz PLL 950 – 1450 F-75 Ohm
15007LCN 10.95 – 11.70 0.7 +/- 50 kHz PLL 950 – 1700 N-50 Ohm
HS1027BN 12.25 – 12.75 0.7 +/- 2 kHz PLL 950 – 1450 N-50 Ohm
HS1028BN 12.25 – 12.75 0.8 +/- 2 kHz PLL 950 – 1450 N-50 Ohm
HS1029AN 11.70 – 12.20 0.9 +/- 2 kHz PLL 950 – 1450 N-50 Ohm
HS1037AN 11.70 – 12.20 0.7 +/- 3 kHz PLL 950 – 1450 N-50 Ohm
HS1047CN 10.95 – 11.70 0.7 +/- 4 kHz PLL 950 – 1700 N-50 Ohm
HS1057AN 11.70 – 12.20 0.7 +/- 5 kHz PLL 950 – 1450 N-50 Ohm
1108HCF 10.95 – 11.70 0.8 +/- 10 kHz PLL 950 – 1450 F-75 Ohm
1207HAF 11.70 – 12.20 0.7 +/- 25 kHz PLL 950 – 1450 F-75 Ohm
HS1027BF 12.25 – 12.75 0.7 +/- 2 kHz PLL 950 – 1450 F-75 Ohm
HS1027CF 10.95 – 11.70 0.7 +/- 2 kHz PLL 950 – 1700 F-75 Ohm
HS1029BF 12.25 – 12.75 0.9 +/- 2 kHz PLL 950 – 1450 F-75 Ohm
HS1038AF 11.70 – 12.20 0.8 +/- 3 kHz PLL 950 – 1450 F-75 Ohm
HS1047BF 12.25 – 12.75 0.7 +/- 4 kHz PLL 950 – 1450 F-75 Ohm
HS1049BF 12.25 – 12.75 0.9 +/- 4 kHz PLL 950 – 1450 F-75 Ohm
1108HFN-2 11.70 – 12.75 0.8 +/- 10 kHz PLL 950 – 2000 N-50 Ohm
1109HAN 11.70 – 12.20 0.9 +/- 10 kHz PLL 950 – 1450 N-50 Ohm
1208HD-2 10.70 – 11.80 0.8 +/- 25 kHz PLL 950 – 2050 F-75 Ohm
1209HCN 10.95 – 11.70 0.9 +/- 25 kHz PLL 950 – 1700 N-50 Ohm
15009LBN 12.25 – 12.75 0.9 +/- 50 kHz PLL 950 – 1450 N-50 Ohm
15008LCN 10.95 – 11.70 0.8 +/- 50 kHz PLL 950 – 1700 N-50 Ohm
15007LA 11.70 – 12.20 0.7 +/- 50 kHz PLL 950 – 1450 F-75 Ohm
15007LB 12.25 – 12.75 0.7 +/- 50 kHz PLL 950 – 1450 F-75 Ohm
1107HAF 11.70 – 12.20 0.7 +/- 10 kHz PLL 950 – 1450 F-75 Ohm
1109HBF 12.25 – 12.75 0.9 +/- 10 kHz PLL 950 – 1450 F-75 Ohm
1109HCF 10.95 – 11.70 0.9 +/- 10 kHz PLL 950 – 1700 F-75 Ohm
1208HBF 12.25 – 12.75 0.8 +/- 25 kHz PLL 950 – 1450 F-75 Ohm
HS1028AF 11.70 – 12.20 0.8 +/- 2 kHz PLL 950 – 1450 F-75 Ohm
HS1037BF 12.25 – 12.75 0.7 +/- 3 kHz PLL 950 – 1450 F-75 Ohm
HS1037CF 10.95 – 11.70 0.7 +/- 3 kHz PLL 950 – 1700 F-75 Ohm
HS1039AF 11.70 – 12.20 0.9 +/- 3 kHz PLL 950 – 1450 F-75 Ohm
HS1039BF 12.25 – 12.75 0.9 +/- 3 kHz PLL 950 – 1450 F-75 Ohm
HS1048CF 10.95 – 11.70 0.8 +/- 4 kHz PLL 950 – 1700 F-75 Ohm
HS1049CF 10.95 – 11.70 0.9 +/- 4 kHz PLL 950 – 1700 F-75 Ohm
HS1058BF 12.25 – 12.75 0.8 +/- 5 kHz PLL 950 – 1450 F-75 Ohm
HS1059BF 12.25 – 12.75 0.9 +/- 5 kHz PLL 950 – 1450 F-75 Ohm
1107HCN 10.95 – 11.70 0.7 +/- 10 kHz PLL 950 – 1700 N-50 Ohm
1107HBN 12.25 – 12.75 0.7 +/- 10 kHz PLL 950 – 1450 N-50 Ohm
1107HAN 11.70 – 12.20 0.7 +/- 10 kHz PLL 950 – 1450 N-50 Ohm
1108HF-2 11.70 – 12.75 0.8 +/- 10 kHz PLL 950 – 2000 F-75 Ohm
1108HDN-2 10.70 – 11.80 0.8 +/- 10 kHz PLL 950 – 2050 N-50 Ohm
1208HBN 12.25 – 12.75 0.8 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
1208HGN-2 12.20 – 12.70 0.8 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
1208HEN 10.95 – 12.75 0.8 +/- 25 kHz PLL 950 – 2750 N-50 Ohm
1208HFN-2 11.70 – 12.75 0.8 +/- 25 kHz PLL 950 – 2000 N-50 Ohm
1208HF-2 11.70 – 12.75 0.8 +/- 25 kHz PLL 950 – 2000 F-75 Ohm
1209HAN 11.70 – 12.20 0.9 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
15008LAN 11.70 – 12.20 0.8 +/- 50 kHz PLL 950 – 1450 N-50 Ohm
15008LA 11.70 – 12.20 0.8 +/- 50 kHz PLL 950 – 1450 F-75 Ohm
15009LCN 10.95 – 11.70 0.9 +/- 50 kHz PLL 950 – 1700 N-50 Ohm
HS1028AN 11.70 – 12.20 0.8 +/- 2 kHz PLL 950 – 1450 N-50 Ohm
HS1029BN 12.25 – 12.75 0.9 +/- 2 kHz PLL 950 – 1450 N-50 Ohm
HS1028CN 10.95 – 11.70 0.8 +/- 2 kHz PLL 950 – 1700 N-50 Ohm
HS1037CN 10.95 – 11.70 0.7 +/- 3 kHz PLL 950 – 1700 N-50 Ohm
HS1047BN 12.25 – 12.75 0.7 +/- 4 kHz PLL 950 – 1450 N-50 Ohm
HS1049BN 12.25 – 12.75 0.9 +/- 4 kHz PLL 950 – 1450 N-50 Ohm
HS1048BN 12.25 – 12.75 0.8 +/- 4 kHz PLL 950 – 1450 N-50 Ohm
1108HEF 10.95 – 12.75 0.8 +/- 10 kHz PLL 950 – 2750 F-75 Ohm
1208HAF 11.70 – 12.20 0.8 +/- 25 kHz PLL 950 – 1450 F-75 Ohm
1208HCF 10.95 – 11.70 0.8 +/- 25 kHz PLL 950 – 1700 F-75 Ohm
1209HAF 11.70 – 12.20 0.9 +/- 25 kHz PLL 950 – 1450 F-75 Ohm
HS1027AF 11.70 – 12.20 0.7 +/- 2 kHz PLL 950 – 1450 F-75 Ohm
HS1039CF 10.95 – 11.70 0.9 +/- 3 kHz PLL 950 – 1700 F-75 Ohm
HS1049AF 11.70 – 12.20 0.9 +/- 4 kHz PLL 950 – 1450 F-75 Ohm
HS1058AF 11.70 – 12.20 0.8 +/- 5 kHz PLL 950 – 1450 F-75 Ohm
HS1059AF 11.70 – 12.20 0.9 +/- 5 kHz PLL 950 – 1450 F-75 Ohm
HS1029CN 10.95 – 11.70 0.9 +/- 2 kHz PLL 950 – 1700 N-50 Ohm
HS1037BN 12.25 – 12.75 0.7 +/- 3 kHz PLL 950 – 1450 N-50 Ohm
HS1039BN 12.25 – 12.75 0.9 +/- 3 kHz PLL 950 – 1450 N-50 Ohm
HS1047AN 11.70 – 12.20 0.7 +/- 4 kHz PLL 950 – 1450 N-50 Ohm
HS1058BN 12.25 – 12.75 0.8 +/- 5 kHz PLL 950 – 1450 N-50 Ohm
HS1059CN 10.95 – 11.70 0.9 +/- 5 kHz PLL 950 – 1700 N-50 Ohm
HS1058CN 10.95 – 11.70 0.8 +/- 5 kHz PLL 950 – 1700 N-50 Ohm
HS1058AN 11.70 – 12.20 0.8 +/- 5 kHz PLL 950 – 1450 N-50 Ohm
1108HGN-2 12.20 – 12.70 0.8 +/- 10 kHz PLL 950 – 1450 N-50 Ohm
1109HBN 12.25 – 12.75 0.9 +/- 10 kHz PLL 950 – 1450 N-50 Ohm
1109HCN 10.95 – 11.70 0.9 +/- 10 kHz PLL 950 – 1700 N-50 Ohm
1208HAN 11.70 – 12.20 0.8 +/- 25 kHz PLL 950 – 1450 N-50 Ohm
15008LC 10.95 – 11.70 0.8 +/- 50 kHz PLL 950 – 1700 F-75 Ohm
15007LBN 12.25 – 12.75 0.7 +/- 50 kHz PLL 950 – 1450 N-50 Ohm
15009LC 10.95 – 11.70 0.9 +/- 50 kHz PLL 950 – 1700 F-75 Ohm
15007LC 10.95 – 11.70 0.7 +/- 50 kHz PLL 950 – 1700 F-75 Ohm
1107HBF 12.25 – 12.75 0.7 +/- 10 kHz PLL 950 – 1450 F-75 Ohm
1108HAF 11.7

Norsat 诺赛特品牌及产品应用领域介绍

一、品牌背景

Norsat（诺赛特）成立于1977年，总部位于加拿大，是海能达集团旗下全资子公司，专注于为全球客户提供定制化卫星通信解决方案。作为卫星通信领域的先驱企业，Norsat在抗干扰技术、高频头（LNB）设计及卫星终端集成方面拥有深厚积累，产品广泛应用于远程通信、应急服务、广电传输及军事国防等高难度场景。其核心产品包括抗5G干扰高频头、定制化卫星组件、便携式卫星终端及海事卫星解决方案，凭借高可靠性和低噪声性能，稳居北美及全球高端通信市场前列。

二、产品技术优势

1. 抗5G干扰高频头系列

  • 3100R系列：采用锁相环（PLL）技术，可在C波段将5G干扰信号抑制至-20 dBm以下，搭配BPF-C带通滤波器可实现多频段干扰过滤，适用于卫星天线与5G基站共存的复杂环境。
  • 8225R抗干扰高频头：专为广电行业设计，本振频率15 GHz，噪声温度仅25°K，可滤除机场雷达等地面波干扰，长期稳定运行于国内电视台及监测站。
  • 3420F锁相环高频头：支持12-24V宽电压输入，相位噪声低至-90 dBc/Hz（10kHz频偏），适用于高精度卫星信号接收。

2. 定制化解决方案

  • 卫星天线与滤波器组合：根据用户场景（如高山台、微波台站）提供定制化LNB+滤波器方案，优化天线增益与抗干扰能力。
  • 抗干扰整体方案：提供从设备选型、安装调试到后期维护的全流程服务，曾为中东、东南亚多国广电系统部署抗5G干扰网络。

三、核心应用领域

1. 广电与融媒体中心

  • 电视台信号传输：Norsat高频头（如8225R）稳定支持C波段卫星信号接收，确保高清节目无中断传输。
  • 融媒体中心应急备份：便携式卫星终端可快速搭建临时通信链路，保障重大事件直播或灾害报道的信号覆盖。

2. 中波台与高山台

  • 中波广播信号增强：高频头与大口径天线结合，提升偏远山区广播信号强度，覆盖半径扩展至数百公里。
  • 高山台抗干扰部署：针对海拔3000米以上台站，定制抗雷击、抗低温高频头，确保极端环境下的设备可靠性。

3. 部队与国防通信

  • 战术卫星通信：便携式终端支持快速部署，满足野外作战、边防哨所等场景的加密语音与数据传输需求。
  • 抗干扰通信网络：结合锁相环技术与跳频协议，抵御敌方电磁干扰，保障指挥链路的稳定性。

4. 气象与无线覆盖

  • 气象卫星数据接收：高频头（如3120 PLL系列）支持极低噪声接收，确保气象卫星云图、雷达数据的实时传输。
  • 无线覆盖盲区补充：在偏远山区或海上平台，通过卫星中继实现4G/5G基站信号回传，提升网络覆盖率。

四、典型客户案例

  • 中东某国广电局：部署Norsat抗5G干扰高频头网络，解决C波段卫星信号与5G基站同频干扰问题，信号中断率下降90%。
  • 东南亚某部队：采用便携式卫星终端与高频头组合，实现边境巡逻分队的实时视频回传，指挥响应时间缩短至分钟级。
  • 国内某高山气象站：定制抗低温高频头方案，在-40℃环境下连续运行3年，故障率为零。

五、服务与支持

  • 全球技术支持：24/7技术团队提供远程诊断与现场维护，确保设备全生命周期稳定运行。
  • 定制化培训：针对广电、部队等客户开展高频头调试、抗干扰策略等专项培训，提升用户自运维能力。
  • 备件快速响应：在全球主要城市设立备件库，关键部件（如LNB、滤波器）实现48小时到货。

六、未来展望

随着6G与低轨卫星技术的发展，Norsat正研发新一代抗干扰高频头，支持Ka/Ku/C多频段兼容，并探索AI驱动的智能干扰预测系统。未来，Norsat将持续深耕广电、国防及应急通信领域，为全球客户提供更高效、更安全的卫星通信解决方案



深圳市华视数码科技有限公司提供有效解决方案，最具体性价格。
