Name: Norsat 8520RF C-Band DRO LNB 3.7 - 4.2 GHz ±500 kHz 20K NF, F Type 75 Ohm诺赛特 高频头
SKU: 2905
Availability: InStock

Description

Norsat 8520RF C-Band DRO LNB 3.7 – 4.2 GHz ±500 kHz 20K NF, F Type 75 Ohm诺赛特高频头

8520RF SPECIFICATIONS
Input Frequency				3.70 to 4.20 GHz
L.O. Frequency				5.15 GHz
IF Frequency				950 to 1450 MHz
Noise Temperature				20K
L.O. Stability				±500 KHz
Phase Noise (SSB) max.				-70 dBc/Hz at 1 kHz
				-90 dBc/Hz at 10 kHz
				-100 dBc/Hz at 100 kHz
Input VSWR				2.0:1 max.
Output VSWR				2.2:1 max.
Conversion Gain				62 dB
Output P1dB				8 dBm
DC Power				+15 to +24 V supplied through center conductor of IF cable
Current drain				130 mA
Input (waterproof)				CPR229G waveguide grooved
Output (waterproof)				F-Connector 75 Ohm
Dimensions				180 x 100 x 70mm (7.1 x 4.0 x 2.8 in)
Weight				425 g (15 oz)
