Norsat 3200F-BPF-1, 3.7 - 4.2 GHz C-Band 5G Interference LNB, +/-25 kHz

Norsat 3200F-BPF-1, 3.7 – 4.2 GHz C-Band 5G Interference LNB, +/-25 kHz

Original price was: ¥5,500.00.Current price is: ¥4,680.00.

5G LNB Models

Series	Models	Frequency Band	Rejection Range	L.O. Stability
3000-BPF	3200F-BPF-1	3.70 – 4.20 GHz	< 3.6 GHz and > 4.8 GHz	±25 KHz
	3200F-BPF-2	3.625 – 4.20 GHz	< 3.525 GHz and > 4.8 GHz
	3200F-BPF-3	3.754 – 4.20 GHz	< 3.654 GHz and > 4.8 GHz
	3200F-BPF-4	3.80 – 4.20 GHz	< 3.7 GHz and > 4.8 GHz
	3200F-BPF-5	3.90 – 4.20 GHz	< 3.8 GHz and > 4.8 GHz
	3200F-BPF-6	4.00 – 4.20 GHz	< 3.9 GHz and > 4.8 GHz
	3200F-BPF-7	4.10 – 4.20 GHz	< 4.0 GHz and > 4.8 GHz
	3200F-BPF-8	3.82 – 4.20 GHz	< 3.72 GHz and > 4.8 GHz
	3100F-BPF-1	3.70 – 4.20 GHz	< 3.6 GHz and > 4.8 GHz	±10 KHz
	3100F-BPF-2	3.625 – 4.20 GHz	< 3.525 GHz and > 4.8 GHz
	3100F-BPF-3	3.754 – 4.20 GHz	< 3.654 GHz and > 4.8 GHz
	3100F-BPF-4	3.80 – 4.20 GHz	< 3.7 GHz and > 4.8 GHz
	3100F-BPF-5	3.90 – 4.20 GHz	< 3.8 GHz and > 4.8 GHz
	3100F-BPF-6	4.00 – 4.20 GHz	< 3.9 GHz and > 4.8 GHz
	3100F-BPF-7	4.10 – 4.20 GHz	< 4.0 GHz and > 4.8 GHz
	3100F-BPF-8	3.82 – 4.20 GHz	< 3.72 GHz and > 4.8 GHz
	3000F-BPF-1	3.70 – 4.20 GHz	< 3.6 GHz and > 4.8 GHz	±2 KHz
	3000F-BPF-2	3.625 – 4.20 GHz	< 3.525 GHz and > 4.8 GHz
	3000F-BPF-3	3.754 – 4.20 GHz	< 3.654 GHz and > 4.8 GHz
	3000F-BPF-4	3.80 – 4.20 GHz	< 3.7 GHz and > 4.8 GHz
	3000F-BPF-5	3.90 – 4.20 GHz	< 3.8 GHz and > 4.8 GHz
	3000F-BPF-6	4.00 – 4.20 GHz	< 3.9 GHz and > 4.8 GHz
	3000F-BPF-7	4.10 – 4.20 GHz	< 4.0 GHz and > 4.8 GHz
	3000F-BPF-8	3.82 – 4.20 GHz	< 3.72 GHz and > 4.8 GHz

Categories: C band LNB, LNB

Description
Reviews (0)

Description

3200F-BPF-1 SPECIFICATIONS
Input Frequency				3.7 – 4.20 GHz
L.O. Frequency				5.15 GHz
IF Frequency				950 – 1150 MHz
Rejection Range				< 3.9 GHz and >4.8 GHz
Noise Temperature				37K typ., 60K max. at room temp.@CF
Phase Noise (SSB) max.				-80 dBc/Hz at 1 kHz
				-85 dBc/Hz at 10 kHz
				-95 dBc/Hz at 100 kHz
Input VSWR				2.2:1 max.
Output VSWR				2.5:1 max.
Gain				60 dB typ., 55 dB min., 70 dB max.
Gain Flatness (over full band)				≤ 6 dB p-p
Output P1dB				+9 dBm min.
Interference Rejection Signal				-25 dBm max. with no degradation
DC Power				+12V to +24V DC
Current				400 mA max.
Input (waterproof)				CPR229G waveguide grooved
Output (waterproof)				F-Connector 75 Ohm
Dimensions				159 x 98.5 x 70mm (6.26 x 3.88 x 2.75 in)
Weight				500g (17.64 oz)
Operating Temperature				– 40 to + 60°C
Storage Temperature				– 50 to + 70°C
