DCH-6000P 4K 卫星接收机 解码器 AVS2

DCH-6000P 4K Ultra HD Professional Decoder​

​Product Overview​
The DCH-6000P is a professional-grade 4K Ultra HD decoder compliant with the GB/T 33475.2-2016 (AVS2) industry standard for 4K Ultra HD professional decoders. It supports MPEG-2 (MP@ML & MP@HL), MPEG-4 AVC/H.264, AVS+, and HEVC video decoding, along with AVS2/AVS+/MPEG-2, MPEG-4 AVC/H.264/HEVC high/standard-definition video formats.

Equipped with dual PCMCIA interfaces and advanced digital decoding technology, it decrypts signals via CI conditional access systems (e.g., Conax, NDS, Nagra, Cryptoworks, Irdeto, Mediaguard, Viaccess,永新视博) by swapping PCMCIA modules for satellite/cable/terrestrial digital TV signals

.

​Key Features​

• ​Comprehensive Input/Output Interfaces:
  • Inputs: DVB-S2/ISI/C Tuner, ASI, and TS/IP.
  • Outputs: HD/SD-SDI, AES/EBU, CVBS, HDMI, and analog audio/video interfaces. Optional 4x 3G-SDI or 4x 12G-SDI outputs

    .

• ​Audio Support: Up to 2 embedded audio PID channels or compressed pass-through output; dual-channel AES/EBU digital audio output

  .

• ​Network & Streaming: Full-duplex Gigabit Ethernet supporting UDP/RTP, unicast/multicast, and single/multi-program stream transmission

  .

• ​Decoding & Processing:
  • Built-in re-multiplexing module for PID filtering, source selection, and stream regeneration

    .

  • Tuner, ASI, and TS/IP input redundancy backup

    .

• ​Conditional Access: Dual CI slot descrambling with BISS-1/BISS-E support

  .

• ​Management & Control:
  • Web-based network management and SNMP protocol support

    .

  • Dynamic PMT detection, automatic updates, and RSSI Tuner signal quality monitoring

    .

  • Ethernet, USB upgrade ports, and Alarm (DB9) interface

    .

​Applications​
Designed for content providers, broadcasters, cable/terrestrial TV operators, and digital TV networks, the DCH-6000P meets customized demands for professional signal reception and decoding
