CS-5300A+ Colorsatl anti-5G interference LNB 卡洛斯抗 5G 干扰双本振高频头

Description

CS-5300A+

Model: CS-5300A+
Input Frequency: 3.7 – 4.2GHz
Output Frequency: H: 950~1450MHz; V: 1550~2050MHz
L.O. Frequency: H: 5150MHz; V: 5750MHz
Noise Figure: 17°K (Type)
Gain Flatness: ±4 dB
L.O. Frequency Stability: ±1MHz (+25°C); ±2MHz (-30°C~+80°C)
Cross Polarization Isolation: >20dB (Min.); 23dB (Typ.)
驻波比 2.0:1 (Max.)
Rejection at 3.5GHz: >58dB
Conversion Gain: >65 dB
L.O. Phase Noise @1KHz: -65 dBc
L.O. Phase Noise @10KHz: -95 dBc
L.O. Phase Noise @100KHz: -105 dBc
Output Connector: 75 Ohm F-Type Female
DC  : 11.5 – 24.0V
Weight: 550g
Dimension: 192mm (L) × 73mm (W) × (H not specified in the original text)
