Colorsat Ku band dual polarization twin LNBF CK-120A KU

Original price was: ¥1,200.00.Current price is: ¥280.00.

Compare
Category:

Description

Model型号​:CK-120A
​Input Frequency 输入频率​:11.7~12.75GHz
​Output Frequency 输出频率​:950~2000MHz
​L.O. Frequency 本振频率​:10.75GHz
​Noise Figure 噪声系数​:0.5dB (Min.), 1.1dB (Max.), 0.6dB (Typ.)
​Gain Flatness 增益平坦度​:±0.5 dB / 26 MHz(典型值);±0.5 dB / Full Band(全频段)
​Gain Variation 增益变化量​:7.5dB / Full Band(全频段)
​L.O. Frequency Stability 本振频率稳定度​:±0.5MHz (max.) @ +25℃;±1.5 MHz (max.) @ -40℃~+60℃
​Cross Polarization Isolation 极化隔离​:20dB (Min.);23dB (Typ.)
​Output VSWR 输出驻波比​:2.5:1 (max.)
​Conversion Gain 转换增益​:>65 dB(最小值)
​L.O. Phase Noise 本振相位噪声​:-60 dBc/Hz @ 1 KHz;-80 dBc/Hz @ 10 KHz
​Image Rejection 镜像抑制干扰​:40 dB (min.)
​P1 dB Compression Point 1dB压缩点​:0 dBm (min.)
​Output Connector 输出连接头​:75 Ohm F-Type Female(75欧姆母接头)
​DC Current Consumption 消耗电流​:200mA (max.)
​DC Voltage Supply 直流电压输入​:12.0~14.0 V @ LP(低功率模式);16.0~20.0 V @ HP(高功率模式)
​Operating Temperature 工作温度​:-40℃~+60℃
