Colorsat anti-5G interference twin LNBF CS-8200T 卡洛斯 抗 5G 干扰双输出高频头

Description

卡洛斯抗 5G 干扰双输出高频头Colorsat anti-5G interference twin LNBF

CS-8200T

CS-8200T Technical Specifications​

​Model: CS-8200T
​Input Frequency: 3.7~4.2 GHz
​Output Frequency: 950~1450 MHz
​L.O. Frequency (Local Oscillator)​: 5150 MHz
​L.O. Frequency Stability: ±2 MHz (-40℃ ~ +80℃)
​Noise Figure: 17°K (Typical)
​Gain Flatness: ±0.5 dB/36 MHz
​Input V.S.W.R (Voltage Standing Wave Ratio)​: 2.5:1
​Output V.S.W.R: 2.5:1
​LOCAL Leakage at Input (Image Rejection)​: -45 dBm
​Gain: >65 dB (Minimum)
​L.O. Phase Noise: -65 dBc/Hz @ 1KHz; -95 dBc/Hz @ 10KHz; -105 dBc/Hz @ 100KHz
​Image Rejection (Interference)​: 50 dB
​Cross Polar Isolation (H/V Polarization)​: 23 dB MIN
​DC Supply Voltage: 11-14.5 V (V Mode), 15.5-22 V (H Mode)
​Supply Current: 170 mA (MAX)
​Operating Temperature: -40℃ ~ +80℃
​Relative Humidity (Storage)​: 0%~95%
​Input Connector: WAVE GUIDE WC-229 “F” TYPE FEMALE (2 PCS)
​Output Connector: 75 OHMS
