BPF-C-1-EOL C-Band 5G Bandpass Filter Norsat 5G滤波器
Rejects terrestrial interference in C-Band (5G, Radar and C-Band transmitter)
| KEY SPECIFICATIONS |
| band |
C-Band |
| group delay variation within 0.5MHz |
0.6 nsec |
| input frequency band 1 |
3.70 – 4.20 GHz |
| rejection |
25 dB min at 3.650 GHz and 4.250 GHz; 60 dB min at 3.550 GHz and 4.350 GHz; 70 dB min at 3.500 GHz and 4.400 GHz |
| Product Revision |
A |
| RF SPECIFICATIONS |
| VSWR |
1.4 : 1 max. |
| INTERFACE SPECIFICATIONS |
| RF input connector |
CPR 229G waveguide grooved |
| RF output connector |
CPR-229F |
| ENVIRONMENTAL SPECIFICATIONS |
| IP rating |
IP 67 |
| PHYSICAL SPECIFICATIONS |
| product height |
70 mm |
| product length |
120 mm |
| product weight |
0.65 kg |
| product width |
100 mm |
