AVS+编码器 转码器 SDI ASI IP HDMI 复用

AVS+编码器 转码器 SDI ASI IP HDMI 复用

  • ​Industrial-grade 19-inch 1U standard chassis​ with ​dual built-in power supplies​ for enhanced reliability and continuous operation.
  • ​Embedded Web Server​ supporting unified configuration and management via remote web login.
  • ​Video encoding: Supports ​AVS+​​ and ​AVS​ video compression formats.
  • ​Audio encoding: Supports ​MPEG‑1 Layer II, ​MPEG‑1 Layer III (MP3)​, ​LC‑AAC, ​HE‑AAC, ​AC‑3, and ​E‑AC‑3​ audio formats.
  • ​Video capture: Supports ​4× SDI​ inputs for baseband video acquisition.
  • ​Input video standards: Compatible with ​576i​ and ​480i​ video input formats.
  • ​IP input: Accepts ​SPTS/MPTS over UDP​ transport stream IP input for flexible network-based program sources.
  • ​IP output: Supports ​UDP​ output in both ​unicast​ and ​multicast​ modes for efficient delivery.
  • ​ASI output: Provides ​2× DVB‑ASI​ transport stream outputs for downstream processing or distribution.
  • ​Internal multiplexer: Combines multiple re‑encoded ​SPTS​ program streams into a single ​MPTS​ output.
  • ​On‑screen graphics: Supports ​logo insertion​ and ​scrolling text, with adjustable ​logo color, ​size, and ​position.
  • ​Dual Gigabit Ethernet ports: Allows flexible configuration of physical channels for ​IP program input/output.
  • ​Robust and reliable: Engineered for ​7×24‑hour​ nonstop operation in demanding environments.
Compare
Category:

Description

产品特色
(1)工业级19 英寸1U 标准设备，内置双电源
(2)内嵌Web Server，支持远程Web 页面登陆后的统一配置管理
(3)支持AVS+，AVS 视频编码格式
(4)支持MPEG-1 layer 2，MPEG-1 layer 3，LC-AAC，HE-AAC，AC3，EAC3 音频编码格
式
(5)支持视频采集方式：4 路SDI
(6)支持576i，480i 等视频输入制式
(7)支持SPTS，MPTS over UDP 传输流IP 输入
(8)支持UDP（单播、组播）协议输出
(9)支持2 路DVB-ASI 码流输出
(10)支持内部复用器，可将多路编转码后的SPTS 节目流复用为MPTS 节目流输出
(11)支持添加台标、滚动字幕等功能，而且还支持对台标的颜色和大小及位置进行调
整
(12)支持两个千兆以太网口，可灵活配置IP 节目的输入、输出物理通道
(13)设备运行稳定，支持7×24 小时不间断工作
