Description

CCTV Meteorological Satellite Ground Receiving Station

Portable Automatic Weather Station

① Supports satellite meteorological and hydrological broadcasting data reception systems;

② Supports the DVB-S data transmission standard;

③ Supports the IP data broadcasting reception standard;

④ Equipped with F-type RF input and output interfaces in imperial units;

⑤ Antenna material is carbon fiber, with a diameter of no less than 1.2 meters.             It can download signals from C-band satellite antennas, amplify and convert the signals, and restore them into IP data packet parameters in the form of a network card;

USB Data Demodulation Box

① Compliant with the DVB-S standard EN 300 421 specification and the DVB-S/MPEG-2 standard;

② Supports DVB-S satellite receiving function;

③ IP data reception complies with data broadcasting standards;

④ Supports data pipeline transmission;

⑤ Supports TCP/IP/UDP protocols;

⑥ Supports IP unicast, multicast reception, and MAC filtering, with simultaneous demultiplexing of 32 PID channels, each with a maximum data rate of 54 Mbps;

⑦ Supports IP unicast and multicast reception;

⑧Supports 22 kHz output and DISEQC 0/1.2 standard switching.

PCI Data Demodulation Card

It can download signals from C-band satellite antennas, amplify and convert the signals, and restore them into IP data packet parameters in the form of a network card;

① Compliant with the DVB-S standard (EN 300 421) and the DVB-S/MPEG-2 standard;
② Supports DVB-S satellite receiving function;
③ IP data reception complies with data broadcasting standards;
④ Supports data pipeline transmission;
⑤ Supports TCP/IP/UDP protocols;
⑥ Supports IP unicast, multicast reception, and MAC filtering, with simultaneous demultiplexing of 32 PID channels (each PID channel has a maximum data rate of 54 Mbps);
⑦ Supports IP unicast and multicast reception;
⑧ Supports 22 kHz output and DISEQC 0/1.2 standard switching.
