11300 LNB Ku BAND LNB 6C 134 138 ACTOX

Description

11300 LNB Ku BAND LNB 6C 134 138 ACTOX

12.25-12.75 GHz 950 – 1450 MHz

Conversion gain 55 to 70 dB Gain flatness 4 dB p-p max.
Input VSWR 2.5 : 1 typ. Output VSWR 2.5 : 1 typ.
IF connector “F” or “N” – type female IF impedance 75 or 50 ohms
RF interface WR – 75 waterproof Gain ripple 1 dB p-p max per 36 MHz
Phase noise 100 Hz -70 dBc/Hz Noise figure 0.8 dB max.
1 KHz -80 dBc/Hz. Power supply +12 – +24 VDC
10 KHz -85 dBc/Hz Current 200 mA max.
100 KHz -105 dBc/Hz Leakage -55 dBm max.
Operating temperature -40C – +60C Storage temperature -40C – + 80C
Dimensions (mm) 125 x 60 x 22 Weight (g) 300
