卡洛斯专业抗5G干扰高频头Colorsat professional anti-5G interference LNB CS-8100W

Description

卡洛斯专业抗5G干扰高频头Colorsat professional anti-5G interference LNB CS-8100W

Model: CS-8100W
​Input Frequency: 3.7 – 4.2 GHz
​Output Frequency: 950 – 1450 MHz
​L.O. Frequency (Local Oscillator)​: 5.15 GHz
​Noise Figure: 17°K (Type)
​Conversion Gain: >65 dB (Minimum)
​Gain Flatness: ±0.5 dB / 26 MHz
​Gain Variation: ±5 dB / Full Band
​L.O. Frequency Stability: ±150 KHz (max.) @ -40℃ ~ +60℃
​1dB Compression Point (P1dB)​: 5 dBm (Max.)
​Output VSWR (Voltage Standing Wave Ratio)​: 1.9 : 1 (max.)
​5G Signal Rejection: >45 dB@3.6 GHz; 2 – 58 dB@3.6 GHz (Note: The second value seems to be a typo and may represent a range or specific condition)
​Output Connector: 75 Ohm F-Type Female (75欧姆母接头)
​Input Connector: CPR-229G Waveguide Grooved Waterproof (Waveguide waterproof groove interface)
​DC Voltage Supply: 11.5 – 24.0 V
​DC Current Consumption: 200 mA (max.)
​Operating Temperature: -40℃ ~ +70℃
​Storage Temperature: -40℃ ~ +80℃
​Relative Humidity: 0% – 95%
​Construction: Aluminum (Aluminum alloy body for lightweight and durability)
​Dimension: 190 (L) × 115 (W) × 78 (H) mm
​Gross Weight: 620 g (Weight including packaging)
