Showing 33–48 of 48 results
-
Model型号：CK-1075K Input Frequency 输入频率：11.7~12.75GHz Output Frequency 输出频率：950~2000MHz L.O. Frequency 本振频率：10.75GHz Noise Figure 噪声系数：0.5dB (Min.), 1.1dB (Max.), 0.6dB (Typ.) Gain Flatness 增益平坦度：±0.5 dB / 26 MHz（典型值）；±0.5 dB / Full Band（全频段） Gain Variation 增益变化量：7.5dB / Full Band（全频段） L.O. Frequency Stability 本振频率稳定度：±0.5MHz (max.) @ +25℃；±1.5 MHz (max.) @ -40℃~+60℃ Cross Polarization Isolation 极化隔离：20dB (Min.)；23dB (Typ.) Output VSWR 输出驻波比：2.5:1…
-
Colorsat Ku band split-type LNB CS-1130K 本振11.3GHz 卡洛斯高频头 LNB Model型号：CS-1130K Input Frequency 输入频率：12.25 – 12.75 GHz Output Frequency 输出频率：950~1450 MHz L.O. Frequency 本振频率：11.3 GHz Noise Figure 噪声系数：0.3dB (Typical) Conversion Gain 增益：>65 dB（最小值） Gain Flatness 增益平坦度：<5 dB LO Stability 本振频率稳定度：±150KHz Output VSWR 输出驻波比：2.5:1 (Maximum) L.O. Phase Noise 本振相位噪声：-65dBc/Hz @ 1KHz; -80dBc/Hz @ 10KHz; -92dBc/Hz @ 100KHz…
-
Project Overview This project plans to build a satellite signal source scheduling and transmission system, primarily serving the transmission and scheduling/switching of satellite signals from the new central equipment room and a remote backup signal source. The system construction is as follows: System integration for the original equipment room’s satellite reception: After reception at the…
-
GARDINER GX107127B Ku Band BUC 10.7GHz~12.7GHz Band 400W . Functional Specifications Convert input L-band signals to Ku-band output; Amplify the Ku-band output signal to the specified power level; Equipped with squelch control function, enabling the device to operate or mute; Possess gain adjustment function; Possess detection functions for gain, power, temperature, and reflected power; Equipped with…
-
GARDINER GX1315A Ku Band BUC 13GHz~15GHz Band 200W Functional Specifications Convert input L-band signals to Ku-band output; Amplify the Ku-band output signal to the specified power level; Equipped with squelch control function, enabling the device to operate or mute; Possess gain adjustment function; Possess detection functions for gain, power, temperature, and reflected power; Equipped with…
-
GARDINER GX1721A Ku Band BUC 17GHz~21GHz Band 200W 一. Functional Specifications Convert input L-band signals to Ka-band output; Amplify the Ka-band output signal to the specified power level; Equipped with squelch control function, enabling the device to operate or mute; Possess gain adjustment function; Possess detection functions for gain, power, temperature, and reflected power;…
-
GARDINER GX27-31A Ku Band BUC 27GHz~31GHz Band 200W . Functional Specifications Convert input L-band signals to Ka-band output; Amplify the Ka-band output signal to the specified power level; Equipped with squelch control function, enabling the device to operate or mute; Possess gain adjustment function; Possess detection functions for gain, power, temperature, and reflected power;…
-
Frequency Parameters (GHz) Parameter RF IF LO RF (Extended) IF (Extended) LO (Extended) Standard Frequency Bands 14.0-14.5 0.95-1.45 13.05 N/A N/A N/A 10.7-11.7 0.95-1.95 9.75 N/A N/A N/A 11.7-12.75 1.10-2.15 10.60 N/A N/A N/A Extended Frequency Bands 13.75-14.5 0.95-1.70 12.80 13.75-14.5 0.95-1.70 (Reused) 12.80 (Reused) (Reused for comparison with above bands) Key Performance Metrics Parameter…
-
Ku波段平板天线变频器 Frequency Parameters (GHz) Parameter RF IF LO RF (Extended) IF (Extended) LO (Extended) Standard Frequency Bands 14.0-14.5 0.95-1.45 13.05 N/A N/A N/A 10.7-11.7 0.95-1.95 9.75 N/A N/A N/A 11.7-12.75 1.10-2.15 10.60 N/A N/A N/A Extended Frequency Bands 13.75-14.5 0.95-1.70 12.80 13.75-14.5 0.95-1.70 (Reused) 12.80 (Reused) (Reused for comparison with above bands) Key Performance Metrics…
-
一、工作频率(GHz) 变频类型 频段 射频 (GHz) 中频 (GHz) 本振 (GHz) 上变频 标准频段 14.0-14.5 0.95-1.45 13.05 上变频 扩展频段 13.75-14.5 0.95-1.70 12.80 下变频 标准频段 10.7-11.7 0.95-1.95 9.75 下变频 扩展频段 (射频1) 10.7-11.7 0.95-1.95 9.75 下变频 扩展频段 (射频2) 11.7-12.75 1.10-2.15 10.60 特点： Ku全波段覆盖：项目支持Ku波段（12-18GHz）的全波段覆盖，具体体现在上变频和下变频的频段设置上。 上/下变频合一：项目设备同时支持上变频和下变频功能，可根据需求选择。 二、增益(衰减0dB时) 变频类型 频段 增益 上变频 标准频段 21dB 下变频 标准频段 40dB 特点补充： 增益可定制：根据客户需求，增益范围可进行定制。 三、P1dB输出功率 变频类型 频段 P1dB输出功率…
-
Technical Specification of GX Series LNB Power Supply and Control Unit by Shenzhen Huashi Digital Technology Co., Ltd. I. Product Overview The GX Series LNB Power Supply and Control Unit developed by Shenzhen Huashi Digital Technology Co., Ltd. is a specialized device designed for low-noise block downconverters (LNBs) in satellite communication systems. Housed in a…
-
Model型号 Input Frequency (GHz) Noise Figure (dB) LO Stability LO Type Output Frequency (MHz) RF Output Connector 1008DXN-1 10.7 – 11.7 0.8 Locked Ext.Ref. External 950 – 1950 N-50 Ohm 1008DXF-2 10.95 – 11.7 0.8 Locked Ext.Ref. External 950 – 1700 F-75 Ohm 1008DXF-1 10.7 – 11.7 0.8 Locked Ext.Ref. External 950 – 1950 F-75…
-
Norsat LNB 诺赛特 高频头 低噪声放大器 降频器 全系列高频头 批发 Model / Input Frequency / Noise Figure / LO Stability / LO Type / Output Frequency / RF Output Connector / Datasheet 型号 频率 噪声 1008DXN-1 频率 10.7 – 11.7 GHz 0.8 dB Locked…
-
我们非常重视您的业务，我们能够为您提供快速、专业的技术支持服务，让你无后顾之忧！
欢迎技术、商务咨询18688706870，解决您的专业问题。
具体技术和商务请咨询我司。
-
X-Band Up/Down Converter This X-band up/down converter enables frequency conversion between the X-band and L-band. The product adopts a platform-based structural design, and its frequency range can be customized. It supports both remote control and local control at the device end, and features voltage and current alarm protection functions. This product offers excellent performance and…
-
卡洛斯 KU 双极化双输出高频头Colorsat Ku band dual polarization twin LNBF CK-120E 11.3 Model型号：CK-120E Input Frequency 输入频率：12.25 – 12.75 GHz Output Frequency 输出频率：950~1450 MHz L.O. Frequency 本振频率：11.3 GHz Noise Figure 噪声系数：0.3dB (Typical) Conversion Gain 增益：>65 dB（最小值） Gain Flatness 增益平坦度：<5 dB LO Stability 本振频率稳定度：±150KHz Output VSWR 输出驻波比：2.5:1 (Maximum) L.O. Phase Noise 本振相位噪声：-65dBc/Hz @ 1KHz; -80dBc/Hz @ 10KHz; -92dBc/Hz…
