KU-BAND SINGLE MULTI BAND PLL 2000 Series Norsat Noise Figure 0.7 dB typ., 0.8 dB max. at room temp. @ CF (room temperature: 17°C) 0.8 dB typ., 0.9 dB max. at room temp. @ CF 0.9 dB typ., 1.0 dB max. at room temp. @ CF L.O. Stability ±10kHz, ±25 kHz Phase Noise (SSB) max….
Technical Specification of GX Series LNB Power Supply and Control Unit by Shenzhen Huashi Digital Technology Co., Ltd. I. Product Overview The GX Series LNB Power Supply and Control Unit developed by Shenzhen Huashi Digital Technology Co., Ltd. is a specialized device designed for low-noise block downconverters (LNBs) in satellite communication systems. Housed in a…
LS201 L-Band RF Switch The LS201 1U rack-mounted L-band RF switch is a RF channel switching system designed for satellite signal transmission systems. Key Features Automatic & Manual Switching: Supports automatic switching with individually configurable threshold levels for each channel, and manual switching to forcibly switch channels. It allows setting working channel level thresholds—when…
835频率范围：11.70-12.20GHz，本振：10.75GHz NJR-2836频率范围：12.25-12.75GHz，本振：11.30GHz NJR-2837频率范围：10.95-11.70GHz，本振：10.00GHz NJR-2839频率范围：11.20-11.70GHz，本振：10.25GHz 本振频率稳定度： 型号后缀标识U为1ppm相当于5KHz 型号后缀标识S为3ppm相当于15KHz 型号后缀标识H为10ppm相当于50KHz L波段输出信号接口：F型和N型，75和50欧姆 矩形波导口WR-75，增益：55-60dB，供电电压：12-24V，功耗电流：200mA，重量：260
NJT8315 JRC Ku 4W 12.70-13.20GHz BUC 功放 2W Lower Ku-band 2W/4W BUC MODEL No. NJT8315 & NJT8316 series Item Specifications 4W Model: NJT8316 series 2W Model: NJT8115 series Output Interface Waveguide, WR-75 (with Groove) Input Interface N-type female connector, 50 ohms / F-type female connector, 75 ohms Output Power @ 1dB G.C.P. (P1dB) +36.0…
NJT8316L JRC Ku 4W 12.70-13.20GHz BUC 功放 2W Lower Ku-band 2W/4W BUC MODEL No. NJT8315 & NJT8316 series Item Specifications 4W Model: NJT8316 series 2W Model: NJT8115 series Output Interface Waveguide, WR-75 (with Groove) Input Interface N-type female connector, 50 ohms / F-type female connector, 75 ohms Output Power @ 1dB G.C.P. (P1dB) +36.0…
Norsat 3020XF C-Band PLL LNB 3.4 – 4.2 GHz External Reference F Type 75 Ohm 诺赛特 高频头 3020XF SPECIFICATIONS Input Frequency 3.40 to 4.20 GHz L.O. Frequency 5.15 GHz IF Frequency 950 to 1750 MHz Noise Temperature 20K typ., 24K max. L.O. Stability Phase Locked to External Reference Phase Noise (SSB) max. Depends on External…
LNB C BAND PLL 3120F 3120N at room temp. @CF 25K: 25K typ., 28K Max. 30K: 30K typ., 32K Max. L.O. Stability ± 2 kHz to ± 25 kHz Phase noise (SSB) max. – 80 dBc/Hz at 1kHz – 85 dBc/Hz at 10kHz – 95 dBc/Hz at 100kHz Input VSWR 2.2 : 1 max. Output…
3120RF SPECIFICATIONS Input Frequency 3.70 to 4.20 GHz L.O. Frequency 5.15 GHz IF Frequency 950 to 1525 MHz Noise Temperature 20K typ., 24K max. L.O. Stability ±5 KHz Phase Noise (SSB) max. -73 dBc/Hz at 1 kHz -83 dBc/Hz at 10 kHz -93 dBc/Hz at 100 kHz Input VSWR 2.5:1 max. Output VSWR 2.5:1 max….
Noise Temperature 20K: 20K typ., 24K Max. at room temp. @CF 25K: 25K typ., 30K Max. L.O. Stability ±5 kHz, ±10 kHz Phase Noise (SSB) max. -73 dBc/Hz at 1 kHz -83 dBc/Hz at 10 kHz -93 dBc/Hz at 100 kHz Input VSWR 2.5 : 1 max. Output VSWR 2.5 : 1 max. Gain 60…
5G LNB Models
| Series | Models | Frequency Band | Rejection Range | L.O. Stability |
|
3000-BPF
|
3200F-BPF-1 | 3.70 – 4.20 GHz | < 3.6 GHz and > 4.8 GHz |
±25 KHz
|
| 3200F-BPF-2 | 3.625 – 4.20 GHz | < 3.525 GHz and > 4.8 GHz | ||
| 3200F-BPF-3 | 3.754 – 4.20 GHz | < 3.654 GHz and > 4.8 GHz | ||
| 3200F-BPF-4 | 3.80 – 4.20 GHz | < 3.7 GHz and > 4.8 GHz | ||
| 3200F-BPF-5 | 3.90 – 4.20 GHz | < 3.8 GHz and > 4.8 GHz | ||
| 3200F-BPF-6 | 4.00 – 4.20 GHz | < 3.9 GHz and > 4.8 GHz | ||
| 3200F-BPF-7 | 4.10 – 4.20 GHz | < 4.0 GHz and > 4.8 GHz | ||
| 3200F-BPF-8 | 3.82 – 4.20 GHz | < 3.72 GHz and > 4.8 GHz | ||
| 3100F-BPF-1 | 3.70 – 4.20 GHz | < 3.6 GHz and > 4.8 GHz |
±10 KHz
|
|
| 3100F-BPF-2 | 3.625 – 4.20 GHz | < 3.525 GHz and > 4.8 GHz | ||
| 3100F-BPF-3 | 3.754 – 4.20 GHz | < 3.654 GHz and > 4.8 GHz | ||
| 3100F-BPF-4 | 3.80 – 4.20 GHz | < 3.7 GHz and > 4.8 GHz | ||
| 3100F-BPF-5 | 3.90 – 4.20 GHz | < 3.8 GHz and > 4.8 GHz | ||
| 3100F-BPF-6 | 4.00 – 4.20 GHz | < 3.9 GHz and > 4.8 GHz | ||
| 3100F-BPF-7 | 4.10 – 4.20 GHz | < 4.0 GHz and > 4.8 GHz | ||
| 3100F-BPF-8 | 3.82 – 4.20 GHz | < 3.72 GHz and > 4.8 GHz | ||
| 3000F-BPF-1 | 3.70 – 4.20 GHz | < 3.6 GHz and > 4.8 GHz |
±2 KHz
|
|
| 3000F-BPF-2 | 3.625 – 4.20 GHz | < 3.525 GHz and > 4.8 GHz | ||
| 3000F-BPF-3 | 3.754 – 4.20 GHz | < 3.654 GHz and > 4.8 GHz | ||
| 3000F-BPF-4 | 3.80 – 4.20 GHz | < 3.7 GHz and > 4.8 GHz | ||
| 3000F-BPF-5 | 3.90 – 4.20 GHz | < 3.8 GHz and > 4.8 GHz | ||
| 3000F-BPF-6 | 4.00 – 4.20 GHz | < 3.9 GHz and > 4.8 GHz | ||
| 3000F-BPF-7 | 4.10 – 4.20 GHz | < 4.0 GHz and > 4.8 GHz | ||
| 3000F-BPF-8 | 3.82 – 4.20 GHz | < 3.72 GHz and > 4.8 GHz |
3220F SPECIFICATIONS Input Frequency 3.40 to 4.20 GHz L.O. Frequency 5.15 GHz IF Frequency 950 to 1750 MHz Noise Temperature 20K typ., 24K max. L.O. Stability ±10 KHz Phase Noise (SSB) max. -80 dBc/Hz at 1 kHz -85 dBc/Hz at 10 kHz -95 dBc/Hz at 100 kHz Input VSWR 2.2:1 max. Output VSWR 2.5:1 max….
噪声温度 20K-30K
视型号而异
增益参数 62dB
输出 P1dB 压缩 9dBm
本振稳定度
（在工作温度指标范围内）
相位噪声（SSB）±2kHz ~ ±25kHz
视型号而异-80dBc/Hz（1kHz）
-85dBc/Hz（10kHz）
-95dBc/Hz（100kHz）
输入电压 +12 至+24V，通过 IF 线缆的中心导体供电
功耗电流 250mA
输入波导接口 CPR-229G
输入 VSWR 2.2 : 1
输出 VSWR 2.2 : 1
频率范围
输入频率（GHz） 3.40~4.20
本振频率（GHz） 5.15
输出频率（MHz） 950~1750
尺寸 144（长）x70（宽）x98（高）m/m
（5.7×2.8×3.9 英寸）
重量 500g/17.6 盎司
温度范围 -40°C ~ +60°C
相对湿度 0~100%有冷凝
Norsat 4106B Ku LNB 诺赛特高频头 降频器 下变频器
Norsat 4106C Ku LNB 12.2-12.7GHz Lo11.25GHz 诺赛特高频头 降频器 下变频器
