Showing 1–16 of 21 results
11300 LNB Ku BAND LNB 6C 134 138 ACTOX 12.25-12.75 GHz 950 – 1450 MHz Conversion gain 55 to 70 dB Gain flatness 4 dB p-p max. Input VSWR 2.5 : 1 typ. Output VSWR 2.5 : 1 typ. IF connector “F” or “N” – type female IF impedance 75 or 50 ohms RF interface…
Noise temperature: ≤150K Gain: 50dB. Gain ripple: ≤±2.5dBp-p. Output P1dB: 5dBm. Input VSWR: ≤3.0:1. Output VSWR: ≤2.0:1. Interfaces: Input WR75-G. Output SMA-K. Power supply SMA-K. Power supply: DC 12~24V, ≤120mA. Dimensions: 92×48×40mm. Weight: About 400g. Working temperature: -40°C ~ +60°C. 2) Ku down converter Part no.: GX1218K Input frequency: 10~16GHz, divided into six bands,…
卡洛斯抗 5G 干扰双输出高频头Colorsat anti-5G interference twin LNBF CS-8200T CS-8200T Technical Specifications Model: CS-8200T Input Frequency: 3.7~4.2 GHz Output Frequency: 950~1450 MHz L.O. Frequency (Local Oscillator): 5150 MHz L.O. Frequency Stability: ±2 MHz (-40℃ ~ +80℃) Noise Figure: 17°K (Typical) Gain Flatness: ±0.5 dB/36 MHz Input V.S.W.R (Voltage Standing Wave Ratio): 2.5:1 Output V.S.W.R: 2.5:1 LOCAL…
GARDINER 嘉顿F11701220 product Specifications Input Frequency 输入频率 Low Band: 11.7 ~ 12.2 GHz Output Frequency 输出频率 Band: 950 ~1450 MHz L.O. Frequency 本振频率 Band: 10.75 GHz Noise Figure 噪声系数 0.5dB (Min.),1.1dB (Max.),0.6 dB(Type) Conversion Gain (Room Temp.) 转换增益（常温） 60dB (min.) / 67 dB (max.) Gain Flatness 增益平坦度 ±0.5 dB / 26 MHz Gain Variation 增益变化量 7.5dB…
Input Frequency 输入频率 Low Band: 10.70 ~ 11.70 GHz High Band: 11.70 ~ 12.75 GHz Output Frequency 输出频率 Low Band: 950 ~ 1950 MHz High Band: 1100 ~ 2150 MHz L.O. Frequency 本振频率 Low Band: 9.75 GHz High Band: 10.60 GHz Noise Figure 噪声系数 0.5dB (Min.),1.1dB (Max.),0.6 dB(Type) Conversion Gain (Room Temp.) 转换增益（常温） 60dB (min.) /…
GARDINER 2836S Ku Band LNB Input Frequency 输入频率 Low Band: 12.25 ~ 12.75 GHz Output Frequency 输出频率 Band: 950 ~ 2150 MHz L.O. Frequency 本振频率 Band: 11.30 GHz Noise Figure 噪声系数 0.5dB (Min.),1.1dB (Max.),0.6 dB(Type) Conversion Gain (Room Temp.) 转换增益（常温） 60dB (min.) / 67 dB (max.) Gain Flatness 增益平坦度 ±0.5 dB /…
Ku Band LNB 14-14.5GHz 下变频器
Noise temperature: ≤150K Gain: 50dB. Gain ripple: ≤±2.5dBp-p. Output P1dB: 5dBm. Input VSWR: ≤3.0:1. Output VSWR: ≤2.0:1. Interfaces: Input WR75-G. Output SMA-K. Power supply SMA-K. Power supply: DC 12~24V, ≤120mA. Dimensions: 92×48×40mm. Weight: About 400g. Working temperature: -40°C ~ +60°C. 2) Ku down converter Part no.: GX1016K Input frequency: 10~16GHz, divided into six bands,…
KU Feedhorns and Solutions for C-Band Antennas Introduction to KU Feedhorns and Solutions for C-Band Antennas Receiving KU-Band Signals 1. Key Features of KU Feedhorns KU feedhorns are integrated devices used for transmitting and receiving signals in the KU-band (10.7-12.75 GHz) in satellite communications. Their core features include: Dual-Polarization Design Support both dual circular polarization…
Ku-Band LNB 13.5-14.5GHz 下变频器 LNB Ku-Band 13.5-14.5GHz 下变频器 LNB Tx上行频段一体化变频器iN PUT:13.5-14.5GHzLO:12.55GHzOut PUT:950-2150MHz
KU-BAND SINGLE MULTI BAND PLL 2000 Series Norsat Noise Figure 0.7 dB typ., 0.8 dB max. at room temp. @ CF (room temperature: 17°C) 0.8 dB typ., 0.9 dB max. at room temp. @ CF 0.9 dB typ., 1.0 dB max. at room temp. @ CF L.O. Stability ±10kHz, ±25 kHz Phase Noise (SSB) max….
LS201 L-Band RF Switch The LS201 1U rack-mounted L-band RF switch is a RF channel switching system designed for satellite signal transmission systems. Key Features Automatic & Manual Switching: Supports automatic switching with individually configurable threshold levels for each channel, and manual switching to forcibly switch channels. It allows setting working channel level thresholds—when…
835频率范围：11.70-12.20GHz，本振：10.75GHz NJR-2836频率范围：12.25-12.75GHz，本振：11.30GHz NJR-2837频率范围：10.95-11.70GHz，本振：10.00GHz NJR-2839频率范围：11.20-11.70GHz，本振：10.25GHz 本振频率稳定度： 型号后缀标识U为1ppm相当于5KHz 型号后缀标识S为3ppm相当于15KHz 型号后缀标识H为10ppm相当于50KHz L波段输出信号接口：F型和N型，75和50欧姆 矩形波导口WR-75，增益：55-60dB，供电电压：12-24V，功耗电流：200mA，重量：260
NJT8315 JRC Ku 4W 12.70-13.20GHz BUC 功放 2W Lower Ku-band 2W/4W BUC MODEL No. NJT8315 & NJT8316 series Item Specifications 4W Model: NJT8316 series 2W Model: NJT8115 series Output Interface Waveguide, WR-75 (with Groove) Input Interface N-type female connector, 50 ohms / F-type female connector, 75 ohms Output Power @ 1dB G.C.P. (P1dB) +36.0…
NJT8316L JRC Ku 4W 12.70-13.20GHz BUC 功放 2W Lower Ku-band 2W/4W BUC MODEL No. NJT8315 & NJT8316 series Item Specifications 4W Model: NJT8316 series 2W Model: NJT8115 series Output Interface Waveguide, WR-75 (with Groove) Input Interface N-type female connector, 50 ohms / F-type female connector, 75 ohms Output Power @ 1dB G.C.P. (P1dB) +36.0…
